Radio Design Labs SF-BNC2 Bidirectional Unbalanced Stereo Audio Network Interface

Name: Radio Design Labs SF-BNC2 Bidirectional Unbalanced Stereo Audio Network Interface
Brand: Radio Design Labs
SKU: SF-BNC2
Price: 849.60 GBP
Availability: OutOfStock

£849.60inc. VAT

£708.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £283.20 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Network ConnectorRJ45 with Link and Speed indicators

Digital Audio Ethernet ProtocolDante

Transmission Rate100 Mbps

Sample Rates Supported44.1 kHz, 48 kHz (default), 88.2 kHz, 96 kHz

Bit Depth Supported-20 dBFS = -10 dBV

Reference Level0 dBFS = +10 dBV

Inputs (4)Mini-jack Stereo or RCA jacks (2, L and R)

Input Level (for +4 dBu/-20 dBFS)-10 dBV nominal

All 25 specifications

Description

The SF-BNC2 is a bidirectional Dante audio network interface. It features two unbalanced audio inputs (left and right) on RCA or stereo 3.5 mm Mini-jack connectors, as well as two unbalanced audio outputs (left and right) on RCA and stereo 3.5 mm Mini-jack connectors. Special software is not required to configure the SF-BNC2. Each input provides a network digital audio level of -20 dBFS for an unbalanced -10 dBV input. Each output provides -10 dBV unbalanced for a network digital audio level of -20 dBFS. The SF-BNC2 is a professional grade product for studio quality fidelity and low noise performance.

Full specifications Datasheet Compare alternatives

The SF-BNC2 is PoE powered. Valid PoE power and synchronization to the Dante network is indicated by a green LED visible from the front of the unit.

The SF-BNC2 is constructed in a durable, professional all-metal enclosure suitable for free-standing, surface-mounted or rack-mounted operation. This full-featured SYSFLEX® product is engineered and manufactured in the U.S.A for continuous duty in demanding installations. The versatility of SYSFLEX® products adds enormous flexibility in the design and installation of professional A/V systems.

Key features:

• Dante Network Interface for Two Audio Inputs and Two Audio Outputs

• Inputs and Outputs on Front-Panel RCA Jacks and Stereo 3.5 mm Mini-Jacks

• Selectable Dante Sample Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

• Converts Two Unbalanced Line-Level Audio Sources to Dante Network Channels

• Converts Two Dante Network Audio Signals to Unbalanced Line Level

• Special Software Not Required for Module Setup

• Exceptional Low-Noise and Low-Distortion Performance

• High Resolution 24 Bit Digital to Analog Conversion

• Legendary RDL Analog Filtering Enhances Superb Audio Performance

• LED Indicator for Valid Power and Network Sync

• Operation from PoE Power (Class 0, IEEE 802.3af)

• Equipped for SysFlex® Rack Mounting or Surface Mounting

Manufacturer part number SF-BNC2.

Key features

Network Connector

RJ45 with Link and Speed indicators

Digital Audio Ethernet Protocol

Dante

Transmission Rate

100 Mbps

Sample Rates Supported

44.1 kHz, 48 kHz (default), 88.2 kHz, 96 kHz

Bit Depth Supported

-20 dBFS = -10 dBV

Reference Level

0 dBFS = +10 dBV

Inputs (4)

Mini-jack Stereo or RCA jacks (2, L and R)

Input Level (for +4 dBu/-20 dBFS)

-10 dBV nominal

Technical specifications

Connectivity

Network ConnectorRJ45 with Link and Speed indicators

Digital Audio Ethernet ProtocolDante

Sample Rates Supported44.1 kHz, 48 kHz (default), 88.2 kHz, 96 kHz

Bit Depth Supported-20 dBFS = -10 dBV

Inputs (4)Mini-jack Stereo or RCA jacks (2, L and R)

Input Level (for +4 dBu/-20 dBFS)-10 dBV nominal

Input Level (maximum)+10 dBV

Input Impedance> 15 kΩ

Outputs (4)Mini-jack Stereo or RCA jacks (2, L and R)

Output Level (operating)-10 dBV nominal

Output Level (maximum)+10 dBV

Output Impedance40 Ω

General

Transmission Rate100 Mbps

Reference Level0 dBFS = +10 dBV

Frequency Response20 Hz to 20 kHz (± 0.5 dB)

Noise below -20 dBFS (20 to 20 kHz)< -80 dB

Crosstalk< -70 dB (20 Hz to 20 kHz)

THD+N< 0.1%

Headroom20 dB

Noise< -75 dB (below -10 dBV)

Headroom above -10 dBV20 dB

Indicators (3)Ethernet Link and Speed (2, rear panel); Sync (front panel)

Ambient Operating Environment0° C to 50° C

Power RequirementPoE Class 0, IEEE 802.3af

Specification ConditionsGain/Level: ± 1 dB; Source termination: 150 Ω; A to D values measured in digital domain

Documents

Radio Design Labs SF-BNC2 Bidirectional Unbalanced Stereo Audio Network Interface — RDL Datasheet
