Home / Amplifiers / Radio Design Labs SAS-HC8 Headphone Amplifier with Source Selection for SourceFlex Distributed Audio System

Radio Design Labs

Radio Design Labs SAS-HC8 Headphone Amplifier with Source Selection for SourceFlex Distributed Audio System

Name: Radio Design Labs SAS-HC8 Headphone Amplifier with Source Selection for SourceFlex Distributed Audio System
Brand: Radio Design Labs
SKU: SAS-HC8
Price: 550.80 GBP
Availability: OutOfStock

£550.80inc. VAT

£459.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £183.60 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Display7-segment red LED (0 = off or Paging; 1 through 8 = selected channel)

Input6-position detachable terminal block

Control ButtonsReplaceable, protected by moisture-resistant polycarbonate

Control functionsMomentary button channel SELECT; Momentary button volume ramp UP; Momentary button volume ramp DOWN

Ramp Rate5 seconds nominal for 40 dB audio level adjustment

Frequency Response50 Hz to 35 kHz (±1 dB)

THD+N< 0.1% (20 Hz to 20 kHz) @ 1 kHz

Control Signalsdc (RAMP and CONTROL conductors between remote Listening Station and Controller)

All 19 specifications

Description

The SAS-HC8 Headphone Control Station is a SourceFlex headphone listening station for use with exercise equipment or on a tabletop. Each unit features a source selector with numeric indicator and volume adjustment buttons. Sealed touch controls protect the internal circuitry from debris and moisture. The rugged metal case is both attractive and durable. If headphones are left unplugged from the SAS-HC8, the internal processor resets the volume to a safe listening level. This averts the possibility of a loud, potentially harmful audio burst when headphones are plugged in.

Full specifications Datasheet Compare alternatives

Key features:

• Headphone listening station for exercise equipment or countertop

• Source selection and volume adjustment buttons

• Sealed touch controls protect internal circuitry

• ULTRASTYLE ™ design rugged metal enclosure

• Mounts to support pipe, handlebar or tabletop

• Automatic volume reduction to safe level when headphones left disconnected

Manufacturer part number SAS-HC8.

Key features

Display

7-segment red LED (0 = off or Paging; 1 through 8 = selected channel)

Input

6-position detachable terminal block

Control Buttons

Replaceable, protected by moisture-resistant polycarbonate

Control functions

Momentary button channel SELECT; Momentary button volume ramp UP; Momentary button volume ramp DOWN

Ramp Rate

5 seconds nominal for 40 dB audio level adjustment

Frequency Response

50 Hz to 35 kHz (±1 dB)

THD+N

< 0.1% (20 Hz to 20 kHz) @ 1 kHz

Control Signals

dc (RAMP and CONTROL conductors between remote Listening Station and Controller)

Technical specifications

Display

Display7-segment red LED (0 = off or Paging; 1 through 8 = selected channel)

Panel Diagram - FrontMetric DXF

Connectivity

Input6-position detachable terminal block

Output Jacks (2)1/4 in. (6.35 mm) headphone jack or 1/8 in. (mini) headphone jack

Amplified Output200 mW RMS into 100 Ω, adjustable (normal system audio input operating level applied)

Power & Physical

MountingBracket with clamps included, mounts to flat surface or to tubing 0.75 in. (1.9 cm) to 1.5 in. (3.8 cm) diameter

Shipping Weight1.455 lbs.

General

Control ButtonsReplaceable, protected by moisture-resistant polycarbonate

Control functionsMomentary button channel SELECT; Momentary button volume ramp UP; Momentary button volume ramp DOWN

Ramp Rate5 seconds nominal for 40 dB audio level adjustment

Frequency Response50 Hz to 35 kHz (±1 dB)

THD+N< 0.1% (20 Hz to 20 kHz) @ 1 kHz

Control Signalsdc (RAMP and CONTROL conductors between remote Listening Station and Controller)

FinishRDL ULTRASTYLE™ design

Ambient Operating Environment0° C to 55° C

DatasheetPDF

Engineering Functional BlockAmerican DXF

sas-hc8.zipTIF

State nameView

Documents

Radio Design Labs SAS-HC8 Headphone Amplifier with Source Selection for SourceFlex Distributed Audio System — RDL Datasheet
