Home / Control Systems / Radio Design Labs SAS-8C 8 Station Audio Controller for SourceFlex Distributed Audio System
Radio Design Labs
Radio Design Labs SAS-8C 8 Station Audio Controller for SourceFlex Distributed Audio System
£1,585.20inc. VAT
£1,321.00 ex. VAT
Out of stock
1
- Visa
- Mastercard
- American Express
- PayPal
Or 3 interest-free payments of £528.40 with PayPal Pay in 3.
4.5 on Trustpilot · 14 reviewsSeen it cheaper? We price-match genuine like-for-like quotes. How it works
Bought in the UK, backed in the UKWhy it matters →
- Sourced through UK distribution
- UK manufacturer warranty
- UK-based engineers
- No import duty or customs charges
- GBP pricing, UK VAT invoices
7 Years Warranty Included
Key specifications
Audio Input, paging100 kΩ balanced or unbalanced line level, detachable terminal block
Audio Inputs, switched (8)100 kΩ balanced or unbalanced line level, detachable terminal block
Audio Input Level-22 dBu to +4 dBu nominal (+22 dBu max.), 25-turn adjustable pot
Control InputPaging Terminal; External closure to ground to activate
Front Panel PresetsDIP switch to set number of inputs used
Metering1 Green LED (intensity indicates audio level) ; 1 Red LED (indicates 0 dB audio level)
Frequency Response50 Hz to 35 kHz (±1 dB)
THD+N< 0.1% @ 1 KHz (bandwidth 20 Hz to 20 kHz)
Description
SAS-8c 8 Station Audio Controller controls eight SourceFlex remote listening station. Six conductor wire connects each remote station with the SAS-8C. The power conductor is protected by an automatically resetting fuse. Use of the SAS-8C in large SourceFlex systems yields the most economical cost per station.
Key features:
• Controls 8 SourceFlex listening stations
• Provision to set maximum listening level at each station
• Auto-resetting fuse protects power feed to each listening station
• Daisy-chain connections to/from SAS-82 and/or SAS-8i
Manufacturer part number SAS-8C.
Key features
Audio Input, paging
100 kΩ balanced or unbalanced line level, detachable terminal block
Audio Inputs, switched (8)
100 kΩ balanced or unbalanced line level, detachable terminal block
Audio Input Level
-22 dBu to +4 dBu nominal (+22 dBu max.), 25-turn adjustable pot
Control Input
Paging Terminal; External closure to ground to activate
Front Panel Presets
DIP switch to set number of inputs used
Metering
1 Green LED (intensity indicates audio level) ; 1 Red LED (indicates 0 dB audio level)
Frequency Response
50 Hz to 35 kHz (±1 dB)
THD+N
< 0.1% @ 1 KHz (bandwidth 20 Hz to 20 kHz)
Technical specifications
Display
Front Panel PresetsDIP switch to set number of inputs used
Connectivity
Audio Input, paging100 kΩ balanced or unbalanced line level, detachable terminal block
Audio Inputs, switched (8)100 kΩ balanced or unbalanced line level, detachable terminal block
Audio Input Level-22 dBu to +4 dBu nominal (+22 dBu max.), 25-turn adjustable pot
Control InputPaging Terminal; External closure to ground to activate
Output, bus24-pin ribbon cable header loop-thru output to drive SAS-82 or SAS-8C
Outputs (4)6-position detachable terminal blocks (connection to remote Listening Station)
Audio Output Gain Range40 dB (trimmer presettable)
Power & Physical
Shipping Weight4.185 lbs.
General
Metering1 Green LED (intensity indicates audio level) ; 1 Red LED (indicates 0 dB audio level)
Frequency Response50 Hz to 35 kHz (±1 dB)
THD+N< 0.1% @ 1 KHz (bandwidth 20 Hz to 20 kHz)
IndicatorsLED; Output voltage present at Remote Outputs
Power Requirement24 Vdc @ 1 A, Ground-referenced
Ambient Operating Environment0° C to 50° C
Documents
Delivery & returns
Estimated delivery 9 Sept - 13 Sept. UK mainland delivery only. Some large or made-to-order items carry longer lead times, shown on the product page.
Unused items in original packaging can be returned within 14 days of delivery — see the returns policy for how business and consumer returns differ. Faulty items are covered under manufacturer warranty and by your statutory rights.
Bought in the UK, backed in the UK
This item is sourced through UK distribution and ships to you from within the UK, so the order never crosses a customs border.
The manufacturer warranty is honoured here in the UK. If something fails, you deal with us, not with an overseas seller in another time zone.
Our own UK-based engineers install, commission and support what we sell, and can attend site when a system needs hands on it.
Delivered within the UK mainland, so there is no import duty, customs charge or courier handling fee waiting for you on delivery.
Prices are in pounds sterling with proper UK VAT invoices, and purchase orders are accepted from approved education accounts: no currency conversion and no surprises at the door.
Payment & security
Pay securely by card. Education customers can apply for a 30-day purchase order account.
Schools, colleges, sixth forms, universities and multi-academy trusts can order on invoice, with no card payment required. Purchase orders and credit terms are for education customers only.
All transactions are processed over an encrypted, secure checkout.
