Home / Mixers / Radio Design Labs RU-MX4T Professional 4 Channel Microphone/Line Mixer with Phantom Power & Transformer - Microphone and line output

Radio Design Labs

Radio Design Labs RU-MX4T Professional 4 Channel Microphone/Line Mixer with Phantom Power & Transformer - Microphone and line output

Name: Radio Design Labs RU-MX4T Professional 4 Channel Microphone/Line Mixer with Phantom Power & Transformer - Microphone and line output
Brand: Radio Design Labs
SKU: RU-MX4T
Price: 615.60 GBP
Availability: OutOfStock

£615.60inc. VAT

£513.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £205.20 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Microphone Inputs (4)2 kΩ balanced, switchable 24 V phantom (IEC 61938: 2013)

Mic Input Level for +4 dBu output-58 to −20 dBu (PHANTOM OFF or ONHI gain); -41 to −4 dBu (PHANTOM ON LO gain)

Line Inputs (4)2 kΩ unbalanced

Line Input Level for +4 dBu out-25 dBV to +20 dBV, -10 dBV nominal

Gain Adjustments (5)Mic: Off to 62 dB gain (PHANTOM OFF ONHI gain); Off to 46 dB gain (PHANTOM ON LO gain); Line: Off to 27 dB gain

Output Attenuator0 dB to infinity

Frequency ResponseMic: 80 Hz to 30 kHz (± 1.5 dB), <-10 dB @ 20 Hz (integral high-pass filter) Line: 20 Hz to 30 kHz (± 0.25 dB)

THD+NMic: < 0.1% (80 Hz to 20 kHz) Line: < 0.02%

All 17 specifications

Description

The RU-MX4 is the ideal choice in many applications where a combination of balanced mic and/or unbalanced line-level signals needs to be mixed. Balanced connections use XLR connectors. Unbalanced signals are coupled through phono jacks. Each of the four inputs can accept either a balanced XLR mic or an unbalanced line-level input. 24 V phantom is individually switch selectable for each mic input. The unbalanced phono jack LINE OUTPUT from one RU-MX4 may connect to the unbalanced input of other equipment, or may be connected to the DIRECT input of another RU-MX4 to expand mixing capabilities. The RU-MX4 provides one balanced output, switchable for mic or line level. Audio levels are adjustable on the front panel. Each input channel is equipped with a front-panel dual-LED VU meter that follows standard VU ballistics. The final mix is displayed on an LED string VU meter featuring a visually comfortable arc motion. A rear-panel switch allows the soft-knee compressor to be switched in or out. A factory installed output isolation transformer is available by ordering the RU-MX4T.

Full specifications Datasheet Compare alternatives

Key features:

• Four Channel Audio Mixer with Expansion Capability

• XLR Microphone Inputs, Phono Jack Line Inputs

• Switchable 24 V Phantom for Each Mic Input

• Mic or Line XLR Output, Switchable

• Unbalanced Line Output and Direct Input

• Integral Compressor/Limiter, Switchable

• Studio-Quality, Low-Noise Performance

Manufacturer part number RU-MX4T.

Key features

Microphone Inputs (4)

2 kΩ balanced, switchable 24 V phantom (IEC 61938: 2013)

Mic Input Level for +4 dBu output

-58 to −20 dBu (PHANTOM OFF or ONHI gain); -41 to −4 dBu (PHANTOM ON LO gain)

Line Inputs (4)

2 kΩ unbalanced

Line Input Level for +4 dBu out

-25 dBV to +20 dBV, -10 dBV nominal

Gain Adjustments (5)

Mic: Off to 62 dB gain (PHANTOM OFF ONHI gain); Off to 46 dB gain (PHANTOM ON LO gain); Line: Off to 27 dB gain

Output Attenuator

0 dB to infinity

Frequency Response

Mic: 80 Hz to 30 kHz (± 1.5 dB), <-10 dB @ 20 Hz (integral high-pass filter) Line: 20 Hz to 30 kHz (± 0.25 dB)

THD+N

Mic: < 0.1% (80 Hz to 20 kHz) Line: < 0.02%

Technical specifications

Connectivity

Microphone Inputs (4)2 kΩ balanced, switchable 24 V phantom (IEC 61938: 2013)

Mic Input Level for +4 dBu output-58 to −20 dBu (PHANTOM OFF or ONHI gain); -41 to −4 dBu (PHANTOM ON LO gain)

Line Inputs (4)2 kΩ unbalanced

Line Input Level for +4 dBu out-25 dBV to +20 dBV, -10 dBV nominal

Output Attenuator0 dB to infinity

Outputs (2)+4 dBu 150 Ω bal. (switchable to MIC level -45 dBu); -10 dBV unbalanced

Power & Physical

Shipping Weight1.845 lbs.

General

Gain Adjustments (5)Mic: Off to 62 dB gain (PHANTOM OFF ONHI gain); Off to 46 dB gain (PHANTOM ON LO gain); Line: Off to 27 dB gain

Frequency ResponseMic: 80 Hz to 30 kHz (± 1.5 dB), <-10 dB @ 20 Hz (integral high-pass filter) Line: 20 Hz to 30 kHz (± 0.25 dB)

THD+NMic: < 0.1% (80 Hz to 20 kHz) Line: < 0.02%

Unity Gain< -84 dB (4 Line level sources)

40dB Gain, Phantom onMic: -79 dB; < -73 dB (All 4 mic level sources)

50dB GainMic: -79 dB; < -73 dB (All 4 mic level sources)

60dB GainMic: -70 dB; < -64 dB (All 4 mic level sources)

Indicators (18)Dual-LED VU meter for each input; COMP/LIMIT active LED; POWER LED; LED audio mix meter, 0 dB = +4 dBu VU (dB): -20, -10, -6, -2, 0, +3; Peak Reading (dB): +8,+12

Ambient Operating Environment0° C to 50° C

Power RequirementGROUND-REFERENCED, 24 Vdc @ 150 mA

Documents

Radio Design Labs RU-MX4T Professional 4 Channel Microphone/Line Mixer with Phantom Power & Transformer - Microphone and line output — RDL Datasheet
