Radio Design Labs RU-ADA8D Audio Distribution Amplifier

Name: Radio Design Labs RU-ADA8D Audio Distribution Amplifier
Brand: Radio Design Labs
SKU: RU-ADA8D
Price: 686.40 GBP
Availability: LimitedAvailability

£686.40inc. VAT

£572.00 ex. VAT

Low stock (2 left), order soon

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £228.80 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Inputs (2)Stereo (A/left and B/right) on detachable terminal block

Input Impedance20 kΩ balanced or 10 kΩ unbalanced

Input Level+4 dBu balanced (nominal), +25 dBu maximum; -10 dBV unbalanced

Input Gain Adjustments (2)-5 dB to +15 dB (rel. +4 dBu balanced); -3 dB to +17 dB (rel. -10 dBV unbalanced)

Input Metering (2)Dual-LED VU Meter for Input A and Input B

Mono modeRear-panel switch-selectable (input A feeds all 16 outputs)

Outputs (16)Stereo, A (8), B (8) on detachable terminal blocks

Output Impedance150 Ω balanced; 75 Ω unbalanced

All 20 specifications

Description

The RU-ADA8D is an eight channel stereo audio distribution amplifier with input and output gain adjustments and input level metering. The module may be operated in mono to provide up to sixteen distributed mono signals. The inputs and outputs are connected on rear-panel detachable terminal blocks.

Full specifications Datasheet Compare alternatives

Each of the two line level inputs accepts either a balanced or an unbalanced signal. Each input is equipped with a front panel INPUT GAIN trimmer. Input signal levels between -14 dBV unbalanced and +9 dBu balanced may be set to the proper operating level as indicated by a dual-LED VU meter. This assures ample headroom at all normal operating levels. The maximum input level is +25 dBu.

A rear-panel switch selects between stereo and mono operation. In the mono position, input A (left) is used to drive all 16 output channels. When the module is used in a monaural system, only input A must be wired.

Audio outputs are isolated from each other and may be wired balanced or unbalanced. Each of the outputs is provided with a front panel screwdriver adjusted OUTPUT LEVEL control. Relative to a balanced +4 dBu output level, this gain potentiometer allows an adjustment range from -9 dB to +6 dB. Relative to an unbalanced -10 dBV output, each output potentiometer allows an adjustment from -3 dB to +12 dB.

The RU-ADA8D offers exceptional headroom, very low distortion, excellent crosstalk isolation, wide flat frequency response and extremely low noise with very high common-mode signal rejection. It provides exceptional audio performance for the most critical applications in a professional audio environment.

The RU-ADA8D operates from 24 Vdc connected through a rear-panel detachable terminal block.

Key features:

• Stereo Audio Distribution with 8 Outputs

• Mono Audio Distribution with 16 Outputs

• Front-Panel Input Level Trimmers

• Dual-LED VU Meter for Each Input Channel

• Front-Panel Output Level Trimmers

• Inputs and Outputs on Rear Panel Detachable Terminal Blocks

• Exceptional Audio Quality for the Most Demanding Applications

Manufacturer part number RU-ADA8D.

Key features

Inputs (2)

Stereo (A/left and B/right) on detachable terminal block

Input Impedance

20 kΩ balanced or 10 kΩ unbalanced

Input Level

+4 dBu balanced (nominal), +25 dBu maximum; -10 dBV unbalanced

Input Gain Adjustments (2)

-5 dB to +15 dB (rel. +4 dBu balanced); -3 dB to +17 dB (rel. -10 dBV unbalanced)

Input Metering (2)

Dual-LED VU Meter for Input A and Input B

Mono mode

Rear-panel switch-selectable (input A feeds all 16 outputs)

Outputs (16)

Stereo, A (8), B (8) on detachable terminal blocks

Output Impedance

150 Ω balanced; 75 Ω unbalanced

Technical specifications

Connectivity

Inputs (2)Stereo (A/left and B/right) on detachable terminal block

Input Impedance20 kΩ balanced or 10 kΩ unbalanced

Input Level+4 dBu balanced (nominal), +25 dBu maximum; -10 dBV unbalanced

Input Gain Adjustments (2)-5 dB to +15 dB (rel. +4 dBu balanced); -3 dB to +17 dB (rel. -10 dBV unbalanced)

Input Metering (2)Dual-LED VU Meter for Input A and Input B

Outputs (16)Stereo, A (8), B (8) on detachable terminal blocks

Output Impedance150 Ω balanced; 75 Ω unbalanced

Output Level+4 dBu balanced (nominal), +24 dBu maximum; -10 dBV unbalanced

Output Level Adjustments (16)-9 dB to +6 dB (rel. +4 dBu, balanced); -3 dB to + 12 dBu (rel. -10 dBV, unbalanced)

Power & Physical

Case dimensions5.75" (14.6 cm)W x 1.65" (4.18 cm)H x 3.54" (9.0 cm)D; 3.9" (9.9 cm)D with connectors

Shipping Weight1.585 lbs.

General

Mono modeRear-panel switch-selectable (input A feeds all 16 outputs)

Frequency Response10 Hz to 165 kHz (+/- 0.25 dB); 10 Hz to 35 kHz (+/- 0.01 dB)

THD+N< 0.0025% (20 Hz to 20 kHz)

Headroom> 20 dB (above +4 dBu input or output)

Noise< -92 dB (below +4 dBu output, 20 Hz to 20 kHz)

Crosstalk< -85 dB (20 Hz to 1 kHz); <-70 dB (1 kHz to 20 kHz)

CMRR> 90 dB (100 Hz)

Ambient Operating Environment0° C to 50° C

Power RequirementGROUND REFERENCED, 24 Vdc @ 140 mA (idle, nominal), 170 mA (max.)

Documents

Radio Design Labs RU-ADA8D Audio Distribution Amplifier — RDL Datasheet
