Radio Design Labs HR-DAC1 Digital to Analog Converter - 24 bit 192 kHz

Name: Radio Design Labs HR-DAC1 Digital to Analog Converter - 24 bit 192 kHz
Brand: Radio Design Labs
SKU: HR-DAC1
Price: 864.00 GBP
Availability: OutOfStock

£864.00inc. VAT

£720.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £288.00 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Ambient Operating Environment0° C to 55° C

StandardsAES3-2003, IEC60958

Indicators (10)POWER LED, blue; LOCK LED, green; RATE: 44.1 kHz, 48 kHz, 96 kHz, 192 kHz; dual-LED VU meters, left and right

Dynamic Range> 110 dB (resolution 24-bit unweighted)

Residual Noise< -100 dB (10 to 20 kHz, -120 dBFS input) < -100 dB (10 to 20 kHz, -120 dBFS input) < -110 dB (locked to digital input, digital audio off)

Phase L to R, R to L±0.15° (5 Hz to 20 kHz)

Output LevelAdjustable OFF to +24 dBu (0 dBFS); Left and Right

Crosstalk< -100 dB (5 Hz to 3 kHz); < -90 dB (3 kHz to 20 kHz)

All 17 specifications

Description

The HR-DAC1 is the ideal choice in installations requiring high quality analog audio from an AES/EBU, AES-3ID or S/PDIF digital audio source. The HR-DAC1 automatically detects a valid input on any of the four input jacks: S/PDIF optical, S/PDIF coaxial, AES-3ID or AES/EBU. The AES/EBU input is 110 Ω terminated; the S/PDIF coaxial and AES-3ID jacks are 75 Ω terminated. A front-panel LOCK LED indicates the presence of a valid digital audio source without any phase-lock or bit errors. Sample rates from 32 kHz to 192 kHz are supported with front-panel LEDs to indicate standard digital audio rates of 44.1 kHz, 48 kHz, 96 kHz and 192 kHz. Professional operating stability is achieved with RDL’s proprietary Sure-Lok™ latch-up auto recovery.

Full specifications Datasheet Compare alternatives

The digital input is converted to stereo audio using high speed delta-sigma conversion, digital filtering and filtered wideband analog drivers. The high performance, low-noise converters are supplemented with digitally controlled analog gating to produce unparalleled performance. The LEFT and RIGHT output levels are individually adjustable using front-panel knobs. A dual-LED VU meter displays the output level of each channel to facilitate level adjustments. Balanced +4 dBu audio outputs are provided on a rear-panel detachable terminal block and on XLR jacks. Unbalanced -10 dBV outputs are provided on phono jacks.

The HR-DAC1 is powered from 24 Vdc, which may be connected through the detachable terminal block or through the dc power jack. A front-panel power switch is provided.

Key features:

• Broadcast Quality Audio Digital to Analog Conversion

• Input: AES/EBU, Coaxial or Optical S/PDIF, AES-3ID

• Outputs: Balanced and Unbalanced Stereo Audio

• Adjustable Audio Output Gain Trim

• Dual-LED Audio Output Level VU Metering

• Operation Up to 24 bits, 192 kHz

• Exclusive Sure-Lok™ Auto-Recovery Sentinel

• Transformer Isolated AES/EBU Input

• Automatic Sample Rate Detection with Indicators

• Digital Signal Lock Indicator for Valid Inputs

Manufacturer part number HR-DAC1.

Key features

Ambient Operating Environment

0° C to 55° C

Standards

AES3-2003, IEC60958

Indicators (10)

POWER LED, blue; LOCK LED, green; RATE: 44.1 kHz, 48 kHz, 96 kHz, 192 kHz; dual-LED VU meters, left and right

Dynamic Range

> 110 dB (resolution 24-bit unweighted)

Residual Noise

< -100 dB (10 to 20 kHz, -120 dBFS input) < -100 dB (10 to 20 kHz, -120 dBFS input) < -110 dB (locked to digital input, digital audio off)

Phase L to R, R to L

±0.15° (5 Hz to 20 kHz)

Output Level

Adjustable OFF to +24 dBu (0 dBFS); Left and Right

Crosstalk

< -100 dB (5 Hz to 3 kHz); < -90 dB (3 kHz to 20 kHz)

Technical specifications

Display

Resolution16 to 24 bits

Connectivity

Output LevelAdjustable OFF to +24 dBu (0 dBFS); Left and Right

Outputs (6)Left and Right: 150 Ω bal. XLR and terminal block, +4 dBu; -10 dBV unbal phono jack

Inputs (4)110 Ω AES/EBU XLR, transformer isolated; S/PDIF optical; 75 Ω S/PDIF coaxial phono jack; 75 Ω AES-3ID BNC

Audio

Dynamic Range> 110 dB (resolution 24-bit unweighted)

Power & Physical

Shipping Weight2.575 lbs.

General

Ambient Operating Environment0° C to 55° C

StandardsAES3-2003, IEC60958

Indicators (10)POWER LED, blue; LOCK LED, green; RATE: 44.1 kHz, 48 kHz, 96 kHz, 192 kHz; dual-LED VU meters, left and right

Residual Noise< -100 dB (10 to 20 kHz, -120 dBFS input) < -100 dB (10 to 20 kHz, -120 dBFS input) < -110 dB (locked to digital input, digital audio off)

Phase L to R, R to L±0.15° (5 Hz to 20 kHz)

Crosstalk< -100 dB (5 Hz to 3 kHz); < -90 dB (3 kHz to 20 kHz)

Harmonic attenuation2nd: -105 dB; 3rd: -108 dB; 4th, 6th: -115 dB; 5th, 7th: -110 dB; above 7th: <-115 dB, typical

THD+N< 0.002% (20 Hz to 20 KHz, below +22 dBu)

Frequency Response5 Hz to 24 kHz (± 0.2 dB into high impedance load)

Sample Rate32 kHz to 192 kHz

Power RequirementGROUND-REFERENCED 24 Vdc @ 175 mA
