Radio Design Labs FP-CH8 Chime Generator - 8 Electronic Chimes

Name: Radio Design Labs FP-CH8 Chime Generator - 8 Electronic Chimes
Brand: Radio Design Labs
SKU: FP-CH8
Price: 421.20 GBP
Availability: OutOfStock

£421.20inc. VAT

£351.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £140.40 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Input50 kΩ balanced or unbalanced

Input Level-20 dBV to 0 dBV

Frequency Response30 Hz to 40 kHz (± 1 dB)

Noise below +4 dBu< -70 dB (unity gain)

Input Level (for +4 dBu out)-18 dBu bal. (-20 dBV unbal.) to +18 dBu bal. (+16 dBV unbal.)

THD+N< 0.05% (1 kHz)

CMRR>70 dB (50 to 150 Hz)

Output150 Ω balanced or 75 Ω unbal.

All 15 specifications

Description

The FP-CH8 is an electronic chime generator that produces eight different synthesized chimes. Each chime can consist of up to 3 tones and 3 harmonics selected to produce sonically natural effects. Certain chimes are single tones and some are a sequence. Each of the 8 chimes is triggered by an individual external closure to ground. A momentary closure to ground is required to start a chime. A single additional CONT (continuous) terminal is also provided. Each chime plays once unless the CONT terminal is grounded. The continuous function causes a chime strike or sequence to repeat until the CONT terminal is ungrounded. This function causes tone chimes (Chimes 4 and 8) to be extended in duration until the CONT terminal is released. Background music or paging audio may be connected to the MUSIC IN input. When a chime plays, the music source will be quickly faded to a level set on the front-panel DUCKING trimmer. The ducking fade depth may be adjusted from 0 dB to fully off, allowing chimes to be mixed with the music or to interrupt the music. The front-panel CHIMING indicator illuminates while music is ducked and a chime is playing. WAIT and IGNORE terminals are provided to prevent or delay chiming action.

Full specifications Datasheet Compare alternatives

Chime patterns are: single strick, double strick, triple strick, tone ring, manual strick, decending triple strick, eurosiren and multi-tone alert.

Key features:

• 8 Individually Selectable Electronic Chimes

• Selectable Single or Repeated Chime

• Synthesized Bell Harmonics for Natural Sound

• External Chime Actuation

• Input for Background Music or Paging Audio

• Automatic Ducking

Manufacturer part number FP-CH8.

Key features

Input

50 kΩ balanced or unbalanced

Input Level

-20 dBV to 0 dBV

Frequency Response

30 Hz to 40 kHz (± 1 dB)

Noise below +4 dBu

< -70 dB (unity gain)

Input Level (for +4 dBu out)

-18 dBu bal. (-20 dBV unbal.) to +18 dBu bal. (+16 dBV unbal.)

THD+N

< 0.05% (1 kHz)

CMRR

>70 dB (50 to 150 Hz)

Output

150 Ω balanced or 75 Ω unbal.

Technical specifications

Connectivity

Input50 kΩ balanced or unbalanced

Input Level-20 dBV to 0 dBV

Input Level (for +4 dBu out)-18 dBu bal. (-20 dBV unbal.) to +18 dBu bal. (+16 dBV unbal.)

Output150 Ω balanced or 75 Ω unbal.

Output Level+4 dBu nominal

Control Inputs (2)TRIG and DISABLE, Pull to ground, 1 mA

Control Outputs (2)PLAYING and EOM, Open-collector @ 25 mA

Power & Physical

DimensionsHeight: 1.36 in. 3.46 cm; Width: 3.25 in. 8.26 cm; Length: 5.0 in. 12.7 cm

Shipping Weight0.87 lbs.

General

Frequency Response30 Hz to 40 kHz (± 1 dB)

Noise below +4 dBu< -70 dB (unity gain)

THD+N< 0.05% (1 kHz)

CMRR>70 dB (50 to 150 Hz)

Ambient Operating Environment0° C to 55° C

Power Requirement24 Vdc @ 60 mA, Ground-referenced

Documents

Radio Design Labs FP-CH8 Chime Generator - 8 Electronic Chimes — RDL Datasheet
