Radio Design Labs AV-XMN4 Four Channel Mic to Dante Interface

Name: Radio Design Labs AV-XMN4 Four Channel Mic to Dante Interface
Brand: Radio Design Labs
SKU: AV-XMN4
Price: 1136.40 GBP
Availability: OutOfStock

£1,136.40inc. VAT

£947.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £378.80 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

7 Years Warranty Included

Key specifications

Network ConnectorRJ45 Neutrik® etherCON®

Digital Audio Ethernet ProtocolDante

Transmission Rate100 Mbps

Sample Rates Supported44.1 kHz, 48 kHz (default), 88.2 kHz, 96 kHz

Bit Depth Supported24 bits

Audio Operating Level-20 dBFS = +4 dBu

Reference Level0 dBFS = +24 dBu

Inputs (4)XLR (female)

All 25 specifications

Description

The AV-XMN4 is an interface that converts four XLR microphone inputs to Dante network audio channels. Special software is not required to configure the AV-XMN4. Each XLR input is equipped with a switch to set the gain for dynamic or condenser microphones. A dual-LED VU meter displays the level for each input to facilitate selection of the ideal gain range. P48 phantom voltage is supplied to each microphone input. The AV-XMN4 is a professional grade product with discrete mic preamplifiers for studio quality fidelity and low noise performance.

Full specifications Datasheet Compare alternatives

The AV-XMN4 may be powered from an external 24 Vdc power supply, available separately. The AV-XMN4 is equipped to operate from a PoE enabled network switch. The AV-XMN4 will reserve power from the switch even while being powered from an external 24 Vdc supply. If PoE power and an external 24 Vdc supply are both feeding an AV-XMN4, the unit will run from the external supply and will seamlessly switch over to PoE power upon loss of the external supply. Valid power and synchronization to the Dante network is indicated by a green LED visible from the front of the unit.

The AV-XMN4 is constructed in a durable, professional all-metal enclosure suitable for use on stage or in studio, or mounted to any flat surface. For fixed installations, mounting brackets are included. The chassis is designed to protect the front panel slide switches from accidental damage. This full-featured AV-PAK product is engineered and manufactured in the U.S.A for continuous duty in demanding installations.

Key features:

• Dante Network Interface for Four Audio Mic Inputs

• Each XLR Input Provides Switch-Selectable Mic Gain: 40 dB, 48 dB or 62 dB

• 48 V Mic Phantom (P48) on each input

• Four XLR Front-Panel Inputs

• Converts Four Standard XLR Mic Audio Sources to Dante Network Channels

• Special Software Not Required for Module Setup

• High Resolution 24 Bit Analog to Digital Conversion

• LED Indicator for Valid Power and Network Sync

• Operation from PoE Power (Class 0, IEEE 802.3af) or external 24 Vdc

• Mounts on a Microphone Stand using an RDL SF-MSM1

Manufacturer part number AV-XMN4.

Call 020 3815 8642

Key features

Network Connector

RJ45 Neutrik® etherCON®

Digital Audio Ethernet Protocol

Dante

Transmission Rate

100 Mbps

Sample Rates Supported

44.1 kHz, 48 kHz (default), 88.2 kHz, 96 kHz

Bit Depth Supported

24 bits

Audio Operating Level

-20 dBFS = +4 dBu

Reference Level

0 dBFS = +24 dBu

Inputs (4)

XLR (female)

Technical specifications

Choose a section to view its specifications.

Connectivity (9)

Network Connector: RJ45 Neutrik® etherCON®
Digital Audio Ethernet Protocol: Dante
Sample Rates Supported: 44.1 kHz, 48 kHz (default), 88.2 kHz, 96 kHz
Bit Depth Supported: 24 bits
Inputs (4): XLR (female)
Input Level (for +4 dBu/-20 dBFS): Mic: -36 dBu (LO), -44 dBu (MED), -58 dBu (HI)
Input Level (maximum): Mic: -16 dBu (LO), -24 dBu (MED), -38 dBu (HI)
Input Impedance: > 2.5 kΩ
Equivalent Input Noise: -130 dBu (62 dB gain); -132 dBu A-Weighted

Audio (1)

Audio Operating Level: -20 dBFS = +4 dBu

Power & Physical (1)

Dimensions: 5.19" (13.18 cm) W; 1.68" (4.27 cm) H; 5.97" (15.16 cm) D

General (14)

Transmission Rate: 100 Mbps
Reference Level: 0 dBFS = +24 dBu
Gain: Mic: 40 dB (LO), 48 dB (MED), 62 dB (HI); front-panel selectable
Phantom Power: P48, 48 Vdc
Standard for Phantom: IEC 61938: 2013
Frequency Response: 20 Hz to 20 kHz (± 0.5 dB)
Noise below -20 dBFS (20 to 20 kHz): Mic: < -72 dB (LO), < -72 dB (MED), < -68 dB (HI)
THD+N: < 0.1% (20 Hz to 20 kHz, +4 dBu/-20 dBFS); 0.015% at 1 kHz (typ)
CMRR: > 65 dB (50 Hz to 120 Hz)
Crosstalk: Below Noise Floor (20 Hz to 20 kHz at operating level, any input to any input, max. mic gain)
Indicators (11): Ethernet Link and Speed (2, rear panel); Sync (front panel); dual-LED VU meter (8 LED, front panel)
Ambient Operating Environment: 0° C to 50° C
Power Requirement: PoE Class 0, IEEE 802.3af, or 24 Vdc @ 500 mA, Ground-referenced
Specification Conditions: Gain/Level: ± 1 dB; Source termination: 150 Ω; A to D values measured in digital domain
