Home / Meeting Room Solutions / Poly Studio X72 All-in-One Video Bar
Poly

Poly Studio X72 All-in-One Video Bar

£6,237.60inc. VAT
£5,198.00 ex. VAT
In stock, dispatched within 3 working days
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • In UK stock, ships from the UK
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 01342 580255
Return within 14 days
Installation services availablePurchase orders: education customers only
1 Year Warranty Included
Key specifications
Product colourBlack
Camera resolution2160p, 4K UHD (3840 x 2160)
Camera typeDual-lens
Total camera megapixels2 x 20 MP
Horizontal field of view120 (wide); 70 (narrow) °
Diagonal field of view140 (wide); 78 (narrow) °
Zoom capability7.3x digital
Lens privacyIntegrated
All 31 specifications

Description

The Poly Studio X72 is Poly's most flexible all-in-one video bar for large meeting rooms. Microsoft Teams, Zoom and Google Meet run natively on the device, and the Poly Video App adds H.323 and SIP calling, so a large room can be equipped without a dedicated room PC.

Full specifications Datasheet Compare alternatives

Imaging comes from two 20 MP 4K sensors, one behind a 120 degree wide lens and one behind a 70 degree narrow lens, with 7.3x digital zoom and an integrated privacy shutter. Poly DirectorAI switches automatically between speaker, people and group framing. Two MEMS microphones and two second-order microphones cover roughly 7.6 m, and NoiseBlockAI and Acoustic Fence remove keyboard noise and conversations happening outside the room.

Sound is handled by a two-way dual speaker system with 2 x 20 W RMS mid drivers and 2 x 15 W RMS tweeters in an acoustic chamber. Two HDMI 2.0 outputs support dual displays, an HDMI 1.4 input takes wired content, and AirPlay, Miracast and digital whiteboarding cover wireless sharing. Extra Poly cameras and table microphones connect over Ethernet as the room grows, and Wi-Fi 6, Bluetooth 5.0 and Poly Lens management are built in.

Supplied by TopAV. Manufacturer part number A4LZ8AA#ABU.

Call 01342 580255

Key features

Dual 4K cameras

Two 20 MP 4K UHD sensors, 120 degree wide and 70 degree narrow horizontal fields of view, 7.3x digital zoom, integrated lens privacy.

Poly DirectorAI framing

Speaker framing, people framing and group framing switch between lenses automatically.

No room PC required

Microsoft Teams, Zoom and Google Meet certified and run natively; Poly Video App adds H.323 and SIP up to 6 Mbps.

Room-filling audio

Two-way dual speakers at 2 x 20 W RMS mid and 2 x 15 W RMS tweeter, with NoiseBlockAI and Acoustic Fence over a 7.6 m pickup range.

Displays and expansion

Two HDMI 2.0 outputs, one HDMI 1.4 input, and Ethernet-connected Poly peripherals such as the Studio E360 and table microphone.

Connectivity

USB Type-C and two USB Type-A at 5 Gbps, gigabit Ethernet, Wi-Fi 802.11ax and Bluetooth 5.0.

Technical specifications

Display
Camera resolution2160p, 4K UHD (3840 x 2160)
People video resolution4K, 30 fps from 2048 Kbps; 1080p, 30 fps from 1024 Kbps; 720p, 30 fps from 512 Kbps
Connectivity
Speaker output power2 x 20 W RMS (mid); 2 x 15 W RMS (tweeter)
External I/O ports1 USB Type-C 5Gbps; 2 USB Type-A 5Gbps; 1 line in; 1 line out; 1 line in (optional microphone); 2 HDMI-out 2.0 (4K @ 30 Hz); 1 HDMI-in 1.4 (4K @ 30 Hz)
Network capabilitiesIPv4; IPv6; 1x 10/100/1G Ethernet; H.323 and/or SIP up to 6 Mbps in Poly Video App mode
WirelessBluetooth 5.0; Wi-Fi 802.11a/b/g/n/ac/ax (MIMO)
Audio
Microphone typeTwo MEMS microphones; two second-order microphones
Microphone pickup range7.62 m
Speaker typeTwo-way dual speakers
Speaker sensitivity83 dB (mid); 89 dB (tweeter)
Audio featuresPoly NoiseBlockAI; Poly Acoustic Fence; automatic gain control
Power & Physical
Product colourBlack
Weight3.3 kg
Product dimensions (W x D x H)840.18 x 135.4 x 117.93 mm
Certifications & Warranty
Certified collaboration softwareMicrosoft Teams; Zoom; Google Meet
WarrantyPoly standard one-year limited warranty
General
Camera typeDual-lens
Total camera megapixels2 x 20 MP
Horizontal field of view120 (wide); 70 (narrow) °
Diagonal field of view140 (wide); 78 (narrow) °
Zoom capability7.3x digital
Lens privacyIntegrated
Smart camera technologyPoly DirectorAI with speaker, people and group framing
Video frame rate5-30 fps (up to 4K at 15 fps in call)
Video standardsH.264 AVC; H.264 High Profile; H.265
Content sharingApple AirPlay; Miracast; digital whiteboarding; HDMI input
Management softwarePoly Lens
SecurityKensington lock slot; AES 128-bit and AES 256-bit encryption; media encryption (H.323, SIP); H.235.6; SCEP
Operating temperature range0 to 40 °C
Heat dissipation65 BTU/h
In the boxPoly Studio X72; wall mount kit; 2 HDMI cables; AC power adapter; power cable
Call 01342 580255

Documents

Poly Studio X72 All-In-One Video Bar datasheet (PDF)
