Poly Studio X70 All-in-One Video Bar with TC10 Touch Controller

Name: Poly Studio X70 All-in-One Video Bar with TC10 Touch Controller
Brand: Poly
SKU: 8L540AA
Price: 7491.60 GBP
Availability: OutOfStock

£7,491.60inc. VAT

£6,243.00 ex. VAT

Out of stock

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

1 Year Warranty Included

Key specifications

Camera resolution2160p, 4K UHD (3840 x 2160)

Camera typeDual-lens

Total camera megapixels2 x 20 MP

Horizontal field of view120 (wide); 70 (narrow) °

Diagonal field of view140 (wide); 78 (narrow) °

Zoom capability7.3x digital

Lens privacyIntegrated

Smart camera technologyPeople framing; group framing; speaker framing; DirectorAI perimeter

All 30 specifications

Description

The Poly Studio X70 is an all-in-one video system for large meeting rooms. It runs Zoom, Microsoft Teams and Google Meet natively on the bar itself, so the room does not need a separate PC, and the Poly Video App adds H.323 and SIP calling for traditional infrastructure. This kit is supplied with a Poly TC10 touch controller for meeting control.

Full specifications Datasheet Compare alternatives

Two 20 MP 4K sensors sit behind a 120 degree wide lens and a 70 degree narrow lens, with 7.3x digital zoom and integrated lens privacy. Poly DirectorAI handles speaker, group and people framing and the DirectorAI perimeter. Two MEMS microphones and two second-order microphones cover about 7.6 m, with NoiseBlockAI and Acoustic Fence filtering out noise and off-room conversations.

Audio is a two-way dual speaker system with 2 x 20 W RMS mid drivers and 2 x 15 W RMS tweeters. Two HDMI outputs drive dual displays, an HDMI input takes wired content, and AirPlay, Miracast and digital whiteboarding cover wireless sharing. Gigabit Ethernet, Wi-Fi 5 and Bluetooth 5.0 are built in, and the estate is managed centrally through Poly Lens.

Supplied by TopAV. Manufacturer part number 8L540AA.

Call 01342 580255

Key features

Dual 4K cameras

Two 20 MP 4K UHD sensors with 120 degree wide and 70 degree narrow horizontal fields of view and 7.3x digital zoom.

Poly DirectorAI

People framing, group framing, speaker framing and DirectorAI perimeter.

Built-in cloud video

Zoom, Microsoft Teams and Google Meet run natively on the bar; Poly Video App adds H.323 and SIP up to 6 Mbps. No room PC required.

Two-way stereo audio

2 x 20 W RMS mid drivers and 2 x 15 W RMS tweeters, with NoiseBlockAI and Acoustic Fence over a 7.6 m microphone pickup range.

Displays and content

Two HDMI outputs for dual displays, one HDMI input, plus Apple AirPlay, Miracast and digital whiteboarding.

Poly TC10 touch controller

1280 x 800 IP touch panel included in this kit, paired over the network.

Technical specifications

Display

Camera resolution2160p, 4K UHD (3840 x 2160)

People video resolution4K, 30 fps from 2048 Kbps; 1080p, 30 fps from 1024 Kbps; 720p, 30 fps from 512 Kbps

Connectivity

Speaker output power2 x 20 W RMS (mid); 2 x 15 W RMS (tweeter)

External I/O ports1 USB Type-C 5Gbps; 2 USB Type-A 5Gbps; 2 RJ-45; 1 audio in; 1 audio out; 2 HDMI-out 1.4; 1 HDMI-in 1.4

Network capabilitiesIPv4; IPv6; 1x 10/100/1G Ethernet; H.323 and/or SIP up to 6 Mbps in Poly Video App mode

WirelessBluetooth 5.0; Wi-Fi 802.11a/b/g/n/ac (MIMO)

Audio

Microphone typeTwo MEMS microphones; two second-order microphones

Microphone pickup range7.6 m

Speaker typeTwo-way dual speakers

Speaker sensitivity83 dB (mid, 1 W/1 m); 89 dB (tweeter, 1 W/1 m)

Audio featuresPoly NoiseBlockAI; Poly Acoustic Fence

Power & Physical

Weight3.2 kg

Product dimensions (W x D x H)840.18 x 135.38 x 117.33 mm

Certifications & Warranty

Certified collaboration softwareZoom; Microsoft Teams; Google Meet

WarrantyPoly standard one-year limited warranty

General

Camera typeDual-lens

Total camera megapixels2 x 20 MP

Horizontal field of view120 (wide); 70 (narrow) °

Diagonal field of view140 (wide); 78 (narrow) °

Zoom capability7.3x digital

Lens privacyIntegrated

Smart camera technologyPeople framing; group framing; speaker framing; DirectorAI perimeter

Video frame rate5-30 fps (up to 4K at 15 fps in call)

Video standardsH.264 AVC; H.264 High Profile; H.265

Content sharingApple AirPlay; Miracast; digital whiteboarding; HDMI input

Management softwarePoly Lens

SecurityKensington lock slot; AES 128-bit and AES 256-bit encryption; H.235.6; BFCP; active directory authentication

Operating temperature range0 to 40 °C

Heat dissipation65 BTU/h

In the boxPoly Studio X70; Poly TC10 touch controller; AC power adapter; 2 HDMI cables; Ethernet cable; wall mount kit
