Home / Fixed Wall Mounts / Peerless IM747PU DesignerSeries Articulating Mount with In-Wall Box for 37" TO 65" ultra thin displays

Peerless

Peerless IM747PU DesignerSeries Articulating Mount with In-Wall Box for 37" TO 65" ultra thin displays

Name: Peerless IM747PU DesignerSeries Articulating Mount with In-Wall Box for 37" TO 65" ultra thin displays
Brand: Peerless
SKU: IM747PU
Price: 465.60 GBP
Availability: OutOfStock

£465.60inc. VAT

£388.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £155.20 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

5 Years Warranty Included

Key specifications

Maximum Load Capacity36.29 kg

Minimum Load Capacity11.34 kg

Minimum Screen Size Supported37" (93.98 cm)

Maximum Screen Size Supported65" (165.10 cm)

VESA Mount CompatibleYes

Mounting Pattern400 x 400

Minimum Mounting Pattern200 x 100

Minimum Tilt Angle-5°

All 25 specifications

Description

Peerless-AV's Articulating Mount with a built-in In-Wall Box is designed to provide a robust solution for low profile/recessed applications requiring access to power and ample space for AV electronics. The articulating mount swings away from the wall to provide access to the rear of the display and components inside the In-Wall Box. IM747PU is ADA compliant when used with displays 2" thick or less. Key features: • Includes Articulating Mount with 400 x 400mm VESA adaptors. • Up to ±90° of side-to-side swive. • Added ±5° of roll for post-installation display leveling without the use of tools. • Up to ±0.5" (13mm) of vertical adjustment for post-installation leveling and height adjustment fine-tuning. • Landscape or portrait mounting options increases display versatility. • Installs between 16" (406mm) stud centers, to a single stud, or directly into a drywall opening. • Knock-outs for 3/4" , 1.0" , 1.25" and 1.5" conduit |Cut-Out Dimensions: 14.4" x 14.4" (365 x 365mm). • Adjustable Trim Ring allows use of 3/8" - 3/4" drywall thickness. Manufacturer part number IM747PU.

Also in this range:IM771PU Full specifications Datasheet Compare alternatives

Key features

Maximum Load Capacity

36.29 kg

Minimum Load Capacity

11.34 kg

Minimum Screen Size Supported

37" (93.98 cm)

Maximum Screen Size Supported

65" (165.10 cm)

VESA Mount Compatible

Yes

Mounting Pattern

400 x 400

Minimum Mounting Pattern

200 x 100

Minimum Tilt Angle

-5°

Technical specifications

Choose a section to view its specifications.

Display (2)

Minimum Screen Size Supported: 37" (93.98 cm)
Maximum Screen Size Supported: 65" (165.10 cm)

Connectivity (1)

Device Supported: Display

Power & Physical (5)

VESA Mount Compatible: Yes
Mounting Pattern: 400 x 400
Minimum Mounting Pattern: 200 x 100
Minimum Adjustable Depth: 4.93 cm (1.94")
Maximum Adjustable Depth: 63.58 cm (25.03")

General (17)

Maximum Load Capacity: 36.29 kg
Minimum Load Capacity: 11.34 kg
Minimum Tilt Angle: -5°
Maximum Tilt Angle: 15°
Brand Name: DesignerSeries
Packaged Quantity: 1 Unit
Product Type: Wall Mount
Features: • Robust; • Swing; • +/- 5° Roll; • Vertical Adjustment; • Cable Tie Slot
Orientation: Landscape/Portrait
Mount Pattern Compatibility Type: Universal
Mount Profile: Low Profile
Minimum Swivel Angle: -90°
Maximum Swivel Angle: 90°
Mount Function: • In-wall Box; • Articulating
Mount Surface: Wall
Durability: Scratch Resistant
Manufacturer Part Number: IM747PU
