Logitech

Logitech Extend Single-Cable BYOD Connection Kit

Name: Logitech Extend Single-Cable BYOD Connection Kit
Brand: Logitech
SKU: 952-000199
Price: 878.40 GBP
Availability: InStock

£878.40inc. VAT

£732.00 ex. VAT

In stock, dispatched within 3 working days

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Maximum extension distanceUp to 100 m

Cable requirementStandard category cable; Cat6a to reach the full 100 m

Display side (RX) portsHDMI 2.0 4K60 4:4:4, 2 x USB 2.0 Type-A, Micro USB management interface, power, RJ45 to table side

Table side (TX) portsSecured USB-C to user laptop, USB-C for optional power supply, RJ45 to display side

Optional laptop power deliveryUp to 100 W

Display side box dimensions (H x W x D)143 x 143 x 34.5 mm

Table side box dimensions (H x W x D)143 x 143 x 34.5 mm

Laptop requirementUSB-C port with DisplayPort Alt Mode

All 24 specifications

Description

Logitech Extend puts a single USB-C cable on the meeting table and connects it to the room's display and conference camera over standard category cabling. Someone walks in, plugs their laptop in and runs the meeting on their own video platform, whether the room is a Rally Bar family appliance in Android mode that they want to bypass, or a straight BYOD room with a USB camera.

Full specifications Datasheet Compare alternatives

The kit is two boxes. The Display Side (RX) unit carries HDMI 2.0 at 4K60 4:4:4, two USB 2.0 Type-A ports for the camera and other AV devices, a Micro USB management interface and the RJ45 link. The Table Side (TX) unit presents the secured USB-C cable to the user's laptop, takes an optional USB-C power supply to deliver up to 100 W back to that laptop, and carries the RJ45 back to the display side. Reach is up to 100 m, using Cat6a to hit the maximum.

The laptop needs a USB-C port with DisplayPort Alt Mode and no drivers; verified operating systems are Windows 10, Windows 11 and the two most recent versions of macOS, and verified cameras include the Rally Bar family, MeetUp and MeetUp 2 among others. Both boxes take VESA 100 x 100 mm mounting or fix through two holes, a 25.4 mm grommet and magnetic cable dock keep the table tidy, and Logitech Sync reports status and pushes firmware. Note that Logitech's published datasheet cites part number 952-000188; 952-000199 is the equivalent regional SKU.

Supplied by TopAV. Manufacturer part number 952-000199.

Key features

Single-cable BYOD

One USB-C cable at the table drives the room display and camera from the user's own laptop

Display side output

HDMI 2.0 at 4K60 4:4:4 plus two USB 2.0 Type-A ports for room AV devices

Reach

Up to 100 m over standard category cabling; Cat6a for the full distance

Optional power delivery

Up to 100 W back to the laptop when a USB-C power supply is fitted to the table side box

Verified compatibility

Rally Bar, Rally Bar Mini, Rally Bar Huddle, MeetUp and MeetUp 2 among others; Windows 10/11 and macOS

Managed in Sync

Status and firmware through Logitech Sync, Zoom Device Management or Teams Admin Center

Technical specifications

Display

Display side (RX) portsHDMI 2.0 4K60 4:4:4, 2 x USB 2.0 Type-A, Micro USB management interface, power, RJ45 to table side

Display side box dimensions (H x W x D)143 x 143 x 34.5 mm

Display requirementHDMI 1.4 or higher

Connectivity

Table side (TX) portsSecured USB-C to user laptop, USB-C for optional power supply, RJ45 to display side

Power & Physical

Table side box dimensions (H x W x D)143 x 143 x 34.5 mm

MountingVESA 100 x 100 mm; 2 through-holes with hardware included

Power supply dimensions73.5 x 53 x 35 mm

Certifications & Warranty

Warranty2-year limited hardware warranty

General

Maximum extension distanceUp to 100 m

Cable requirementStandard category cable; Cat6a to reach the full 100 m

Optional laptop power deliveryUp to 100 W

Laptop requirementUSB-C port with DisplayPort Alt Mode

AV device requirementUSB Type-A 2.0 or higher

Verified camerasRally Bar, Rally Bar Mini, Rally Bar Huddle, MeetUp, MeetUp 2 and more

Verified operating systemsWindows 10, Windows 11, macOS (latest 2 versions)

Power supplyAuto-sensing, 100-240 V, 48 V, 0.5 A

Supplied cablesDC 1.5 m, USB-C to USB-C 1.5 m, USB-A to Micro USB 1 m

Operating temperature0 to 40 C

Storage temperature-25 to 70 C

Humidity10 to 90 %

SecurityFile-based encryption NIST SHA-256; data encryption by public key hash; digitally signed firmware updates

Device managementLogitech Sync

Recycled contentMinimum 40% post-consumer recycled material

In the boxDisplay side (RX) box, table side (TX) box, USB-C to USB-C cable, Micro USB to USB-A cable, power supply, mounting hardware, 25.4 mm grommet, adapter, magnetic dock, documentation

Documents

Logitech Extend datasheet (PDF)
