Home / Switches / Kramer VP-550X 10-Input 4K HDR HDMI Presentation Switcher/Scaler
Kramer

Kramer VP-550X 10-Input 4K HDR HDMI Presentation Switcher/Scaler

£1,566.00inc. VAT
£1,305.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £522.00 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 020 3815 8642
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - MicrophoneOn 3-pin terminal block
Outputs - 2 HDMIOn female HDMI connectors
Inputs - 7 HDMIOn female HDMI connectors
Inputs - 1 USB (providing power)On a USB type-C connector
Inputs - 1 Computer GraphicsOn a 15-pin HD connector
Inputs - 1 Composite VideoOn an RCA connector
Inputs - 3 Unbalanced Stereo Analog Audio (AUX, VGA and CV)On 3-pin terminal blocks
Outputs - 1 Balanced Analog Stereo AudioOn a 5-pin terminal block
All 25 specifications

Description

VP-550X is a versatile, professional presentation scaler/switcher for 4K@60 (4:4:4) HDMI, USB-C, VGA, and composite video signals. The unit scales the video and provides options to use the embedded digital audio or to select analog audio input signals. After processing and scaling, the embedded AV signal is sent to the 2 mirrored HDMI outputs simultaneously, and the audio is also sent to a balanced stereo audio output. Manufacturer part number VP-550X.

Also in this range:VP-427X VP-440X VP-551X Full specifications Datasheet Compare alternatives
Call 020 3815 8642

Key features

High-Performance Switcher/Scaler - Scales HDMI, USB-C (Alt-DP), VGA

High-Performance Switcher/Scaler - Scales HDMI, USB-C (Alt-DP), VGA, and Composite video signals for outputting to two mirrored HDMI outputs. Constant output sync prevents signal disruption when switching between inputs and when no video is detected.

High-Resolution Video - Supports and scales to/from resolutions up to

High-Resolution Video - Supports and scales to/from resolutions up to 4K@60Hz (4:4:4). Complies with HDCP 2.2. Supports HDR10, CEC, xvYCC color (on input), Dolby TrueHD/DTS-HD Master Audio (by-pass), as specified in HDMI 2.0.

Professional Video Quality - Provides selectable aspect ratios (full

Professional Video Quality - Provides selectable aspect ratios (full, best fit, over-scan, under-scan, letter box and pan scan). Includes built-in ProcAmp for color, hue, sharpness, noise, contrast, and brightness control. Supports PixPerfect™, Kramer's precision pixel mapping and high-quality scaling technology with full up-scaling and down-scaling of all video input signals.

Versatile Audio Options - Includes a companion analog audio input for

Versatile Audio Options - Includes a companion analog audio input for each of the 2analog video inputs and an additional AUX audio input - enabling the user to embed analog audio channel into the video signal or to bypass an embedded audio input (for example, to support multi-channel, compressed audio formats like Dolby and DTS). Provides an independent microphone input (with optional 48V phantom power) for mixing, switching or talk-over. On the output, besides the audio embedded on the HDMI outputs, the audio signal is also extracted (de-embedded) and output as a balanced stereo analog audio

Powerful Audio Features - Includes DSP with audio equalization

Powerful Audio Features - Includes DSP with audio equalization, mixing, delay and more.

Versatile Powering Options - Receives power from a universal power

Versatile Powering Options - Receives power from a universal power supply (100-240V AC) and provides up to 18W of power to the USB-C input, HDTV Compatible.

4K and Legacy Inputs - 7 HDMI and 1 USB-C 4K@60 (4:4:4) inputs, 1 VGA

4K and Legacy Inputs - 7 HDMI and 1 USB-C 4K@60 (4:4:4) inputs, 1 VGA input, and 1 CV (composite video) input.

Non-Volatile Memory - Saves final settings before shutdown and

Non-Volatile Memory - Saves final settings before shutdown and retains them for next power up.

Convenient Control Options - Local control via front panel buttons

Convenient Control Options - Local control via front panel buttons (input selection, audio mute, freeze and front panel lock), RS-232, IR remote, and OSD. Long-distance control via Ethernet using embedded web pages.

Easy Installation - 19" enclosure for rack mounting a unit in a 1U

Easy Installation - 19" enclosure for rack mounting a unit in a 1U rack space with included rack ears and universal 100-240V AC power connection.

Technical specifications

Choose a section to view its specifications.

Display (7)
Video - Input HDMI and USB-C Resolutions
480i/576i, 480p/576p, 640x480@60/72/75/85Hz, 720p@60/50Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1080i@60/50Hz, 1080p@24/25/30Hz, 1080p@60/50Hz, 1280x1024@60/75Hz, 1280x720@60Hz, 1280x768@60Hz,
Video - Input Computer Graphics Resolutions
640x480@60/72/75/85Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1280x960@60Hz, 1280x720@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600x120
Video - Input CV Resolution
480I/576i
Video - Output HDMI Resolutions
480p@60Hz, 576p@50Hz, 720p@50/60Hz, 1080p@24/25/30/50/60Hz, 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x720@60Hz, 1280x800@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1400x1050@60Hz, 1440x
Video - Max. Input Resolution - HDMI and USB-C
4K@60Hz (4:4:4)
Video - Max. Input Resolution - VGA
1080p60 / UXGA
Video - Max.Output Resolution- HDMI
4K@60Hz (4:4:4)
Connectivity (12)
Inputs - Microphone
On 3-pin terminal block
Outputs - 2 HDMI
On female HDMI connectors
Inputs - 7 HDMI
On female HDMI connectors
Inputs - 1 USB (providing power)
On a USB type-C connector
Inputs - 1 Computer Graphics
On a 15-pin HD connector
Inputs - 1 Composite Video
On an RCA connector
Inputs - 3 Unbalanced Stereo Analog Audio (AUX, VGA and CV)
On 3-pin terminal blocks
Outputs - 1 Balanced Analog Stereo Audio
On a 5-pin terminal block
Ports - 1 RS-232 (Data)
On a 3-pin terminal block
Ports - 1 RS-232 (Control)
On a 3-pin terminal block
Ports - 1 Ethernet
100Mbps, on an RJ-45 connector
Video - HDMI Support
HDR10, CEC, xvYCC color (on input), Dolby TrueHD/DTS-HD Master Audio (by-pass), as specified in HDMI 2.0
General (6)
Video - Content Protection
Up to HDCP 2.2
Video - Latency
1-2 frames
User Interface - Controls
IR remote, Input selection, freeze, mute, XGA/1080p reset, and panel lock buttons, OSD menu
User Interface - Indicators
IR, selected input LEDs
Power - Source
100-240V AC 50/60Hz
Power - Consumption
1A
