Home / Splitters / Y-Cables / Kramer VM-4UX 1:4 4K 12G SDI DA
Kramer

Kramer VM-4UX 1:4 4K 12G SDI DA

£565.20inc. VAT
£471.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £188.40 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs1 SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST-2082 (12G-SDI) compliant serial video, 75Ω on a BNC connector.
Outputs4 equalized and reclocked SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST 2082 (12G-SDI), outputs 75Ω on BNC connectors.
Cable Equalization Reach12Gbps: Up to 80m (260ft), 3Gbps and 6Gbps: Up to 100m (330ft), 1.5Gbps: Up to 200m (660ft), SD: Up to 300m (980ft), Note: The above specs apply when using Kramer cables.
VideoUp to 4K@60Hz (4:2:2) 30bpp resolution, 270Mbps to 12Gbps data rate.
Maximum Output Level800mVpp /75Ω.
CouplingAC.
Standards ComplianceSMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI), ST-2082 (12G-SDI).
Power Consumption5V DC, 250mA.
All 14 specifications

Description

The VM-4UX is a compact and high performance 1:4 4K distributor for standard broadcast-grade SDI signals of up to 12G transmitted data rate. It auto-adapts to the data rate of one SDI input signal, equalizes and re-clocks the signal to improve transmitted signal reach, and distributes the signal to four identical SDI outputs. Manufacturer part number VM-4UX.

Full specifications Datasheet Compare alternatives

Key features

Reliable Wire Connectivity - Coaxial broadcast-grade cables are

Reliable Wire Connectivity - Coaxial broadcast-grade cables are reliably connected via lockable BNC connectors, preventing unintentional wire disconnections, to gain fast and highly professional uncompressed SDI signals distribution deployments.

Extended-reach Input Extension - Input signal equalization and output

Extended-reach Input Extension - Input signal equalization and output signals reclocking to gain extended-reach signal extension. Using Kramer high-quality coaxial SDI cables, supports extension of up to 300m (984ft) for SD signals; 200m (656ft) for 1.5G HD signals; 100m (328ft) for 3G and 6G HD signals; 80m (262ft) for 12G 4K signals. Note: Reach depends on signal resolution, and quality of copper cable used. Reach extension performance may vary while using non-Kramer coaxial cables.

Transmitted Data Rate - Auto-adapting from 270Mbps to 12Gbps data

Transmitted Data Rate - Auto-adapting from 270Mbps to 12Gbps data rates.

Compliance - Complies with SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M

Compliance - Complies with SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST-2082 (12G-SDI) standards.

Max. Resolution - 4K@60Hz (4:2:2) 30bpp.

Max. Resolution - 4K@60Hz (4:2:2) 30bpp.

SDI Signal Transmission - SDI, HD-SDI, 3G HD-SDI, 6G and 12G SDI

SDI Signal Transmission - SDI, HD-SDI, 3G HD-SDI, 6G and 12G SDI compliant signals, supporting pass-through of standard embedded audio channels with ancillary ID and metadata information.

LED Indicators - Status indicators for transmitted SDI data rate of

LED Indicators - Status indicators for transmitted SDI data rate of input and output connected signals, and power indicator, for ease of maintenance and troubleshooting.

Easy Installation - Compact DigiTOOLS™ fan-less enclosure for small

Easy Installation - Compact DigiTOOLS™ fan-less enclosure for small footprint spaces and over-ceiling mounting, or side-by-side rack mounting.

Technical specifications

Connectivity
Inputs1 SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST-2082 (12G-SDI) compliant serial video, 75Ω on a BNC connector.
Outputs4 equalized and reclocked SMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI) and ST 2082 (12G-SDI), outputs 75Ω on BNC connectors.
Maximum Output Level800mVpp /75Ω.
Power & Physical
Power Consumption5V DC, 250mA.
Certifications & Warranty
Standards ComplianceSMPTE 259M (SD-SDI), 292M (HD-SDI), 344M (ED-SDI), 424M (3G HD-SDI), ST-2081 (6G-SDI), ST-2082 (12G-SDI).
General
Cable Equalization Reach12Gbps: Up to 80m (260ft), 3Gbps and 6Gbps: Up to 100m (330ft), 1.5Gbps: Up to 200m (660ft), SD: Up to 300m (980ft), Note: The above specs apply when using Kramer cables.
VideoUp to 4K@60Hz (4:2:2) 30bpp resolution, 270Mbps to 12Gbps data rate.
CouplingAC.
Power Source5.2V/4A.
EnclosureTools size, Aluminum type.
CoolingConvection ventilation.
Operating Temperature0° to +40°C (32° to 104°F).
Storage Temperature-40° to +70°C (-40° to 158°F).
Humidity10% to 90%, RHL non-condensing

Documents

Kramer VM-4UX 1:4 4K 12G SDI DA — manufacturer spec sheet
Kramer VM-4UX 1:4 4K 12G SDI DA — manufacturer manual
