Kramer SWT3-21-HU-TR 2x1 4K60 USB-C/HDMI Switcher Extender

Hybrid-meeting Collaborative Switching - Controllable coupled-signals switching of both AV and USB host inputs, for concurrent connection with AV output and USB devices, allows collaborative hybrid meeting where meeting participants are switched to share their content with both room and online meeting participants.

BYOD Ease and Convenience - BYOD Ease and Convenience - Connect any DP-Alt-Mode-capable USB-C device as an AV source using a single USB-C cable. The connection also provides USB and Ethernet access, and (if PD-2.0-capable) up to 60 watts of charging power.

High Performance Standard Extender - Professional HDBaseT 3.0 extender for providing long-reach signals over twisted-pair copper infrastructures. SWT3-21-HU-TR is a standard extender that can be connected to any market-available HDBaseT-compliant extension product. For optimum extension reach and performance, use recommended Kramer cables.

HDMI Signal Switching - HDCP 2.3 compliant, supporting deep color, x.v.Color™, CEC, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0b.

Flexible USB Switching and Extension - An active USB 3.2 host is connected to the switcher extender on either the transmitter or receiver sides. USB 2.0 signals are extended between the switcher extender transmitter and receiver sides, enabling connection and switching of the active USB host to both local USB 3.1 and remote USB 2.0 devices, such as camera and audio devices, or HID (Human Interface Devices) mouse or keyboard devices.

HDMI Mirroring - On switcher transmitter side, active USB-C or HDMI input signal is transmitted on HDBT output, and in parallel mirrored to HDMI output port for connecting a local monitor or adding an additional unit in a daisy chain.

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation.

Multi-channel Audio Transmission - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.

Field-configurable HDBT direction - Instantly set the unit's role during power up. The unit is set to either a receiver (with 3 inputs - HDBT, USB-C and HDMI) or a transmitter (with 2 inputs - USB-C and HDMI and one HDBT output).

Audio De-embedding - The digital audio signal passing to the output, is de-embedded, converted to an analog signal and sent to the stereo balanced analog audio output. This enables playing the audio on a locally connected professional audio system (such as DSP) and speakers, in parallel to playing it on the speakers connected to the AV acceptor device (such as TVs with speakers).
