Home / Control Systems / Kramer KT-205WM 5.5 Inch Wall Mounted PoE Touch Panel
Kramer

Kramer KT-205WM 5.5 Inch Wall Mounted PoE Touch Panel

£777.60inc. VAT
£648.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £259.20 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
1 Year Warranty Included
Key specifications
Ports - 1 EthernetOn an RJ-45 (10M/100M/1000M) connector with PoE 802.3at
Ports - 1 Micro USBOn a Micro USB (AB) OTG connector
General - CPU PerformanceARM Quad-core Cortex-A53 up to 1.8GHz (64 bit)
General - System Memory4GB LPDDR4
General - Internal Storage Memory32GB eMMC
General - Touch Panel TypeMulti-touch type
General - Wireless CommunicationWi-Fi 6, 802.11 a/b/g/n/ax/ax, Bluetooth BT 5.0
General - Display ScreenMulti-touch (PCAP)
All 24 specifications

Description

KT-205WM is a new powerful, 5.5 inch, IPS, multi-touch, touch panel with 720x1280 (9:16) resolution. Elegantly designed for wall-mounted decorative room integration. KT-205WM runs the latest Android 11, supports wired PoE (Power over Ethernet) and advanced Wi-Fi connectivity options. The touch panel has a built-in speaker and microphone and comes with a wall mount. The touch panel is easy to assemble, with elegant wiring and secured mounting providing reliable operation and flexible deployment. KT-205WM touch panel is ideal for 24/7 Kramer-supported commercial AV or control applications and features a user-friendly, fully customizable graphical user interface configured by Kramer software. Manufacturer part number KT-205WM.

Full specifications Datasheet Compare alternatives

Key features

Elegant Design - Smooth integration with room design, with flexible

Elegant Design - Smooth integration with room design, with flexible panel cabling and locking design options.

Superior User Experience - IPS 720x1280 hi-resolution screen with

Superior User Experience - IPS 720x1280 hi-resolution screen with ±80° horizontal and vertical wide viewing angles, ambient light sensor, proximity sensor, with advanced multi-touch points and 2-finger gesture capabilities.

Powerful Processing - i.MX8M Plus Quad Core A53, 2GB RAM, 32GB ROM

Powerful Processing - i.MX8M Plus Quad Core A53, 2GB RAM, 32GB ROM processing performance, smoothly running complicated media and graphics-rich applications, such as H.265 video and audio streams encoding and decoding.

Flexible Services - Latest Android 11 operating system.

Flexible Services - Latest Android 11 operating system.

Easy Installation - Powering and connectivity via a single Ethernet

Easy Installation - Powering and connectivity via a single Ethernet cable.

Optional Connectivity - Simple wireless Bluetooth 5 as well as

Optional Connectivity - Simple wireless Bluetooth 5 as well as connection to USB peripheral devices.

Reliable Networking - Seamless switching between wired and wireless

Reliable Networking - Seamless switching between wired and wireless 802.11ac connectivity.

Versatile Powering Options - PoE or power adapter (sold separately).

Versatile Powering Options - PoE or power adapter (sold separately).

Auto Sensing - Optimized performance and operation according to

Auto Sensing - Optimized performance and operation according to automatically detected LAN speed.

Firmware Update - Define automatic updates at a predefined time of

Firmware Update - Define automatic updates at a predefined time of day or update manually using the USB port.

Technical specifications

Display
General - Touch Panel TypeMulti-touch type
General - Display ScreenMulti-touch (PCAP)
General - Display Size5.5" 720x1280 portrait mode
General - Contrast Ratio350cd/m2 brightness, 1000:1 contrast ratio
Connectivity
Ports - 1 EthernetOn an RJ-45 (10M/100M/1000M) connector with PoE 802.3at
Ports - 1 Micro USBOn a Micro USB (AB) OTG connector
General - Wireless CommunicationWi-Fi 6, 802.11 a/b/g/n/ax/ax, Bluetooth BT 5.0
Audio
Audio - Speaker UnitBuilt-in, 1x1W
Audio - Microphone2, Built-in
Audio - Audio CodecsMPEG/OGG/AAC
Power & Physical
General - Wall Mounting ReadyDedicated bracket for easy mounting
General
General - CPU PerformanceARM Quad-core Cortex-A53 up to 1.8GHz (64 bit)
General - System Memory4GB LPDDR4
General - Internal Storage Memory32GB eMMC
General - Back-lightLED Side-light type
Video - Video FormatH.264 / H.265, VC-1, MPEG-4, VP9/VP8
Video - Image CodecsJPEG/BMP/GIF/PNG
Power - PoEPower over Ethernet 802.3af
Power - Source12V/1A DC adapter (optional)
User Interface - ControlsRestart (on top, recessed), Restore factory settings (on-back, recessed), Home (in top)
User Interface - IndicatorsLED sidebars to indicate room status (requires 3rd party integration)
Accessories - IncludedOn-wall mounting bracket, installation screws
Environmental Conditions - Operating Temperature & Humidity0° to +40°C (32° to 104°F), 5% to 85%
Environmental Conditions - Storage Temperature & Humidity-20° to +60°C (-4° to 140°F), 5% to 90%

Documents

Kramer KT-205WM 5.5 Inch Wall Mounted PoE Touch Panel — manufacturer spec sheet
Kramer KT-205WM 5.5 Inch Wall Mounted PoE Touch Panel — manufacturer manual
