Home / Extenders / Kramer EXT3-H-POE-R 4K60 4:4:4 HDR HDMI Receiver with bidirectional PoE, RS-232 & IR over Long-Reach HDBaseT

Kramer

Kramer EXT3-H-POE-R 4K60 4:4:4 HDR HDMI Receiver with bidirectional PoE, RS-232 & IR over Long-Reach HDBaseT

Name: Kramer EXT3-H-POE-R 4K60 4:4:4 HDR HDMI Receiver with bidirectional PoE, RS-232 & IR over Long-Reach HDBaseT
Brand: Kramer
SKU: EXT3-H-POE-R
Price: 459.60 GBP
Availability: OutOfStock

£459.60inc. VAT

£383.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £153.20 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Outputs - 1 HDMIOn a female HDMI connector

Ports - HDBaseT 3.0Input port

Ports - 1 RS-232On a 3-pin terminal block connector for serial link extension

Ports - 1 IROn a 3.5mm mini jack connector

Extension Line - Standard CompressionUp to 40m (130ft) at 4K@60Hz (4:4:4)

Extension LineUp to 70m (230ft) at 4K@30Hz (4:4:4) or full HD (1080p @60Hz 36bpp)

Extension Line - High CompressionUp to 70m (230ft) at 4K@60Hz (4:4:4), 4K@60Hz (4:2:0), or full HD (1080p @60Hz 36bpp)

Extension Line - Standards ComplianceUp to 40m (130ft) at 4K@60Hz (4:2:0)

All 25 specifications

Description

EXT3-H-POE-R is a high-performance, long-reach HDBaseT 3.0 receiver for 4K60 4:4:4 HDR HDMI, RS-232 and IR signals over twisted pair. EXT3-H-POE-R converts the HDBaseT 3.0 signal and outputs it to its HDMI and control ports. It enables extending video signals to up to 40m (230ft) over Kramer copper cables at up to 4K@60Hz (4:4:4) video resolutions. It is compatible with standard HDBaseT-compliant extenders at up to 4K@60Hz 4:4:4 video resolutions. Manufacturer part number EXT3-H-POE-R.

Full specifications Datasheet Compare alternatives

Key features

High Performance Standard Extender - Professional HDBaseT extender

High Performance Standard Extender - Professional HDBaseT extender for providing signals over twisted-pair copper infrastructures. Video signals are received uncompressed with near-zero latency.

PoE powered from either transmitter or receiver unit

Future-proof, Standard Extender - EXT3-H-POE-R is a standard HDBaseT

Future-proof, Standard Extender - EXT3-H-POE-R is a standard HDBaseT extender, backwards compatible with other standard HDBT extenders. It extends uncompressed HDBaseT signals

Intelligent Compression Handling - HDR HDCP 2.3 compliant. Supports

Intelligent Compression Handling - HDR HDCP 2.3 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0b. EDID and CEC signals are passed through from the source to the display.

Multi-channel Audio Extension - Up to 32 channels of digital stereo

Multi-channel Audio Extension - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.

Bidirectional RS-232 Extension - Serial interface data flows in both

Bidirectional RS-232 Extension - Serial interface data flows in both directions, allowing data transmission and device control at baud rates up to 115200 bps with no need for pre configuration.

Bidirectional Infrared Extension - Status LED indicators for HDMI and

Bidirectional Infrared Extension - Status LED indicators for HDMI and HDBT ports facilitate easy local maintenance and troubleshooting. Local firmware upgrade via RS-232 connection ensures lasting, field-proven deployment.

Cost-Effective Maintenance - Status LED indicators for HDMI and HDBT

Cost-Effective Maintenance - Status LED indicators for HDMI and HDBT ports facilitate easy local maintenance and troubleshooting. Local firmware upgrade via RS-232 connection ensures lasting, field-proven deployment.

Easy Installation - Compact DigiTOOLS® fan-less enclosure for

Easy Installation - Compact DigiTOOLS® fan-less enclosure for dropped-ceiling mounting, or side-by-side mounting of 3 units in a 1U rack space with the recommended rack adapter.

Technical specifications

Choose a section to view its specifications.

Connectivity (6)

Outputs - 1 HDMI: On a female HDMI connector
Ports - HDBaseT 3.0: Input port
Ports - 1 RS-232: On a 3-pin terminal block connector for serial link extension
Ports - 1 IR: On a 3.5mm mini jack connector
Video - HDMI Support: Deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0b
EXTENDED BIDIRECTIONAL IR: 20kHz to 100kHz frequency

Power & Physical (1)

Enclosure - Size: DigiTOOLS®

Certifications & Warranty (4)

Extension Line - Standards Compliance: Up to 40m (130ft) at 4K@60Hz (4:2:0)
Video - Compliance: HDCP 2.3, HDR 10
Regulatory Compliance (Standards Compliance) - Safety: CE, UL
Regulatory Compliance (Standards Compliance) - Environmental: RoHs, WEEE

General (14)

Extension Line - Standard Compression: Up to 40m (130ft) at 4K@60Hz (4:4:4)
Extension Line: Up to 70m (230ft) at 4K@30Hz (4:4:4) or full HD (1080p @60Hz 36bpp)
Extension Line - High Compression: Up to 70m (230ft) at 4K@60Hz (4:4:4), 4K@60Hz (4:2:0), or full HD (1080p @60Hz 36bpp)
Extension Line - Note: When using recommended Kramer cables
Video - Max Data Rate: Up to 18Gbps (6Gbps per graphic channel)
EXTENDED BIDIRECTIONAL RS-232: 300 to 115200 baud rate
User Interface - Indicators: IN, OUT, LINK and ON LEDs
User Interface - Controls: DIP-switches
Power - Source: 48V DC
Power - Consumption: 330mA
Environmental Conditions - Operating Temperature: 0° to +40°C (32° to 104°F)
Environmental Conditions - Storage Temperature: -40° to +70°C (-40° to 158°F)
Environmental Conditions - Humidity: 10% to 90%, RHL non-condensing
Enclosure - Type: Aluminum

Documents

Kramer EXT3-H-POE-R 4K60 4:4:4 HDR HDMI Receiver with bidirectional PoE, RS-232 & IR over Long-Reach HDBaseT — manufacturer spec sheet

Kramer EXT3-H-POE-R 4K60 4:4:4 HDR HDMI Receiver with bidirectional PoE, RS-232 & IR over Long-Reach HDBaseT — manufacturer manual
