Home / Extenders / Kramer 691 4K60 4:2:0 HDMI MM/SM Fiber Optic Transmitter with USB, Ethernet, RS-232
Kramer

Kramer 691 4K60 4:2:0 HDMI MM/SM Fiber Optic Transmitter with USB, Ethernet, RS-232

£2,120.40inc. VAT
£1,767.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal
4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 01342 580255
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - 1 HDMIOn HDMI connector,
Inputs - 1 Stereo Analog Unbalanced AudioOn a 3.5mm mini jack
Outputs - 1 fiber opticOn a 10Gbps SFP+ LC connector complying with IEEE 802.3ae
Ports - 1 IROn a 3.5mm mini jack for IR link extension
Ports - 1 USBOn on a female USB-B connector for USB link extension
Ports - 1 RS-232On on a 3-pin terminal block for serial link extension
Ports - 1 100BaseT EthernetOn on an RJ-45 female connector for device control and LAN extension
Extension Line - Optical FiberMulti-mode (MM) or single-mode (SM)
All 25 specifications

Description

691 is a high-performance HDBaseT 2.0 fiber transmitter for ultra-reach extension of 4K60Hz (4:2:0) HDMI, USB, Ethernet, RS-232, IR and stereo audio signals over either multi-mode or single-mode fiber optic. 691 converts all input signals to an HDBaseT 2.0 signal that is transmitted over a fiber optic cable to a compatible receiver that converts it back to the HDMI, USB, Ethernet, RS-232, IR and stereo audio signals. It extends video signals to up to 33km (20.5 miles) over single-mode fiber at up to 4K@60Hz (4:2:0) resolution. 691 includes a multimode OSP+ transceiver, but can be used with a single mode OSP+ transceiver and fiber as well. Manufacturer part number 691.

Full specifications Datasheet Compare alternatives
Call 01342 580255

Key features

High Performance Standard Fiber Extender - HDBaseT 2.0 fiber

High Performance Standard Fiber Extender - HDBaseT 2.0 fiber transmitter for providing ultra-reach signals over either multi-mode or single-mode optical fiber infrastructures, using Kramer pluggable OSP SFP+ units. 691 is a standard fiber extender that can be connected to any market-available HDBaseT-compliant extension product. Note: To ensure specified performance, support, and warranty of this product, use only Kramer's certified hi-performance OSP SFP+ pluggable optical units.

HDMI Signal Extension - HDCP 1.4 compliant. Supports deep color

HDMI Signal Extension - HDCP 1.4 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0. EDID and CEC signals are passed through from the source to the display.

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.

USB Extension - USB 2.0 interface data flows in both directions

USB Extension - USB 2.0 interface data flows in both directions, allowing extension of HID (Human Interface Devices) peripheral devices, such as a mouse or a keyboard. High-bandwidth USB peripheral devices, such as USB isochronous streaming cameras and audio devices, transfer data continuously and periodically. Note: Delivery of their transferred data is not guaranteed by the USB standard and is subject to both USB and HDBaseT line bandwidth management limitations. When such devices are connected, check their functionality to ensure bandwidth limitations are not exceeded.

Ethernet Extension - Ethernet interface data flows in both directions

Ethernet Extension - Ethernet interface data flows in both directions allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control.

Bidirectional RS-232 Extension - Serial interface data flows in both

Bidirectional RS-232 Extension - Serial interface data flows in both directions allowing data transmission and device control.

Bidirectional Infrared Extension - IR interface data flows in both

Bidirectional Infrared Extension - IR interface data flows in both directions allowing remote control of peripheral devices located at either end of the extended line.

Audio Embedding (Adding) - A selectable analog unbalanced stereo

Audio Embedding (Adding) - A selectable analog unbalanced stereo audio input is converted into a digital signal and embedded (added) to the transmitted HDMI signal, replacing the embedded HDMI audio input signal. This enables embedding a selectable audio source over HDMI. For example, a presenter can display a video clip and temporarily override the audio of the source media with another audio source, such as from a microphone.

Cost-Effective Maintenance - Status LED indicators for the HDMI input

Cost-Effective Maintenance - Status LED indicators for the HDMI input and HDBT output link facilitate easy local troubleshooting. Remote device management via built-in web UI and RS-232 connection enable simple device maintenance. Local and remote firmware upgrade via mini-USB, RS-232 or Ethernet connection and the K-Upload tool ensure lasting, field-proven deployment.

Easy Installation - Half 19" 1U rack mountable fan-less enclosure

Easy Installation - Half 19" 1U rack mountable fan-less enclosure enables side-by-side mounting of 2 units in a 1U rack space.

Technical specifications

Display
Video - Max Resolution4K UHD @60Hz (4:2:0) 24bpp resolution
Connectivity
Inputs - 1 HDMIOn HDMI connector,
Inputs - 1 Stereo Analog Unbalanced AudioOn a 3.5mm mini jack
Outputs - 1 fiber opticOn a 10Gbps SFP+ LC connector complying with IEEE 802.3ae
Ports - 1 IROn a 3.5mm mini jack for IR link extension
Ports - 1 USBOn on a female USB-B connector for USB link extension
Ports - 1 RS-232On on a 3-pin terminal block for serial link extension
Ports - 1 100BaseT EthernetOn on an RJ-45 female connector for device control and LAN extension
Extension Line - Optical FiberMulti-mode (MM) or single-mode (SM)
Extension Line - Optical ModuleKramer 10Gbps SFP+ IEEE 802.3ae compliant modules (MM is included)
Multi-mode Line - Typical Optical Transmission Power-2.5dBm
Multi-mode Line - Typical Optical Maximum Loss Budget8.6dB
Single-mode Line - Typical Optical Transmission Power-2.5dBm ,
Single-mode Line - Typical Optical Maximum Loss Budget11.9dB
Certifications & Warranty
Extension Line - ComplianceHDBaseT 2.0
Multi-mode Line - ComplianceG.651.1 OFNR fiber
Single-mode Line - ComplianceG.652D OFNR fiber
STANDARDS COMPLIANCE - Laser Safety ComplianceClass 1
STANDARDS COMPLIANCE - SFP Regulatory CertificationsFDA CDRH 21 CFR 1040 and Laser Notice No. 50, UL and CUL EN60950-2:2007, RoHS6, EMC EN 55022 and EN 55024, IEC 62368-1 and IEC 60825-1 and - 2
General
Multi-mode Line - Nominal Peak Wavelength850 nm
Multi-mode Line - Max Reach over OM3 MM Fiber3km (1.8 miles)
Single-mode Line - Nominal Peak Wavelength1310 nm
Single-mode Line - Max Reach over OS1 SM Fiber33km (20.5 miles)
Video - Max Data Rate10.2Gbps bandwidth (3.4Gbps per graphic channel)
Video - Content ProtectionHDCP 1.4 signal compliance
