Home / Extenders / Kramer 676T 4K60 4:4:4 HDMI and RS-232 Transmitter over Ultra-Reach MM/SM Fiber Optic
Kramer

Kramer 676T 4K60 4:4:4 HDMI and RS-232 Transmitter over Ultra-Reach MM/SM Fiber Optic

£690.00inc. VAT
£575.00 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £230.00 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
3 Years Warranty Included
Key specifications
Inputs - HDMIOn a female HDMI connector
Outputs - Fiber OpticOn LC connector(s)
Ports - RS-232On a 3-pin terminal block connector
Ports - USBOn a female micro USB connector for firmware upgrade
Video - Max Bandwidth18Gbps
Video - Max Resolution4096x2160@60Hz 4K@60 (4:4:4)
Video - ComplianceHDMI 2.0 and HDCP 2.2
Extension Line - Optical FiberMulti-mode (MM) or single-mode (SM)
All 25 specifications

Description

676T is a high-performance HDMI fiber transmitter for ultra-reach extension of 4K@60Hz (4:4:4) HDMI signals. 676T converts the HDMI and RS-232 input signal to an optical signal that is transmitted over a fiber optic cable to a compatible receiver that converts it back to HDMI and RS-232 signals. 676T includes a multi-mode SFP+ transceiver, but can be used with any Kramer certified SFP+ transceiver, such as a single-mode SFP+ transceiver. Manufacturer part number 676T.

Full specifications Datasheet Compare alternatives

Key features

High Performance Standard Fiber Extender - HDMI fiber transmitter for

High Performance Standard Fiber Extender - HDMI fiber transmitter for providing ultra-reach signals over either multi-mode or single-mode optical fiber infrastructures, using Kramer pluggable OSP SFP+ units (multi-mode SFP+ included). Near-zero latency video chroma sub-sampling conversion technology, is employed to auto-adapt above 10G HDMI signals to 10G optical link signal data-rate. Note: To ensure specified performance, support, and warranty of this product, use only Kramer's certified hi-performance OSP SFP+ pluggable optical units.

Multi-drop Signal Distribution - Use optical splitters to extend the

Multi-drop Signal Distribution - Use optical splitters to extend the input signals from a single transmitter to multiple receivers, for displaying the same content on multiple display devices using optical splitting only, with no need for AV distribution amplifiers.

HDMI Signal Extension - HDCP 2.2 compliant and supports up to 18G (6G

HDMI Signal Extension - HDCP 2.2 compliant and supports up to 18G (6G per channel) data rate, LPCM 7.1, Dolby True HD, and DTS-HD as specified in HDMI 2.0.

Power Saving - With CEC ON/OFF function, shut down a display device

Power Saving - With CEC ON/OFF function, shut down a display device automatically when not in use, and auto power it ON upon presentation start.

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID

I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.

Bidirectional RS-232 Extension - Serial interface data flows in both

Bidirectional RS-232 Extension - Serial interface data flows in both directions, to enable data transmission and control of devices.

Cost-Effective Maintenance - Status LED indicators for power, source

Cost-Effective Maintenance - Status LED indicators for power, source, sink and fiber link connections detection facilitate easy local troubleshooting.

Easy Installation - DigiTOOLS® rack mountable fan-less enclosure

Easy Installation - DigiTOOLS® rack mountable fan-less enclosure enables side-by-side mounting of 3 units in a 1U rack space with the recommended rack adapter.

Technical specifications

Display
Video - Max Resolution4096x2160@60Hz 4K@60 (4:4:4)
Connectivity
Inputs - HDMIOn a female HDMI connector
Outputs - Fiber OpticOn LC connector(s)
Ports - RS-232On a 3-pin terminal block connector
Ports - USBOn a female micro USB connector for firmware upgrade
Extension Line - Optical FiberMulti-mode (MM) or single-mode (SM)
Extension Line - Optical ModuleKramer 10Gbps SFP+ IEEE 802.3ae compliant modules (MM is included)
Power & Physical
Video - Max Bandwidth18Gbps
Certifications & Warranty
Video - ComplianceHDMI 2.0 and HDCP 2.2
Multi-mode Line - ComplianceG.651.1 OFNR fiber
Single-mode Line - ComplianceG.652D OFNR fiber
STANDARDS COMPLIANCE - Laser Safety ComplianceClass 1
STANDARDS COMPLIANCE - SFP Regulatory CertificationsFDA CDRH 21 CFR 1040 and Laser Notice No. 50, UL and CUL EN60950-2:2007, RoHS6, EMC EN 55022 and EN 55024, IEC 62368-1 and IEC 60825-1 and - 2
Regulatory Compliance (Standards Compliance) - SafetyCE, UL
Regulatory Compliance (Standards Compliance) - EnvironmentalRoHs, WEEE
General
Multi-mode Line - Max Reach over OM3 MM Fiber3km (1.8 miles)
Single-mode Line - Max Reach over OS1 SM Fiber33km (20.5 miles)
Extended RS-232 - Baud Rate300 to 115200
User Interface - IndicatorsSource detection, sink detection, optical link and power LEDs
User Interface - ControlsReset button.
Power - Consumption480mA
Power - Source12V DC, 2A
Environmental Conditions - Operating Temperature0° to +40°C (32° to 104°F)
Environmental Conditions - Storage Temperature-40° to +70°C (-40° to 158°F)
Environmental Conditions - Humidity10% to 90%, RHL non-condensing

Documents

Kramer 676T 4K60 4:4:4 HDMI and RS-232 Transmitter over Ultra-Reach MM/SM Fiber Optic — manufacturer spec sheet
Kramer 676T 4K60 4:4:4 HDMI and RS-232 Transmitter over Ultra-Reach MM/SM Fiber Optic — manufacturer manual
