INOGENI U-BRIDGE USB-C Extender - USB, DisplayPort Alt Mode and 100W Charging over CAT6A

Name: INOGENI U-BRIDGE USB-C Extender - USB, DisplayPort Alt Mode and 100W Charging over CAT6A
Brand: INOGENI
SKU: U-BRIDGE-USB-C
Price: 1476.00 GBP
Availability: InStock

£1,476.00inc. VAT

£1,230.00 ex. VAT

In stock, dispatched within 2 working days

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £492.00 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

5 Years Warranty Included

Key specifications

In the box1x PC HOST extender module; 1x DEVICE extender module; 1x 1.8 m (6 ft) USB Type-C to Type-C cable; 1x 0.9 m (3 ft) micro-USB to USB-A cable; 1x Quick Start Guide; 2x mounting brackets for the power supply; 2x mounting brackets for the USB-C power supply; 2x mounting brackets for the PC HOST module; 2x mounting brackets for the DEVICE module; 16x black wooden screws; 1x power supply 100-240 V AC in

Link TechnologyHDBaseT 3.0 over CAT6A U/FTP

RangeUp to 70 m (230 ft) at HDMI 4K30; up to 40 m (132 ft) at HDMI 4K60

USB SpeedsUSB 2.0 up to 480 Mbps for extended USB devices; USB 3.2 Gen 1 when extended with an INOGENI U-BRIDGE 3

PC Host Connectors1x USB Type-C host receptacle (video up to 3840x2160p60/4096x2160p60), 1x USB Type-C for the USB-C power supply, 1x RJ45, 1x USB-A USB3-EXT connector

Device Connectors2x USB-A (USB 3.2 Gen 1), 1x USB-C (USB 3.2 Gen 1), 1x USB-C DP Alt Mode source, 1x HDMI 2.0 output, 1x RJ45, 1x USB-B USB3-EXT connector

Available Current (Device)USB-A: 900 mA per port; USB-C: 3 A

HDCP / HDMI ComplianceHDCP 2.3, 2.2 and 1.4; HDMI 2.0b, HDMI 1.4 and DVI 1.0; 600 MHz sampling

All 19 specifications

Description

The INOGENI U-BRIDGE USB-C is a two-module extender that carries full USB-C functionality - USB 2.0, power and DisplayPort Alternate Mode - up to 70 m (230 ft) over a single CAT6A U/FTP cable using HDBaseT 3.0, while also passing Ethernet LAN connectivity to the laptop. The DEVICE module provides USB-A and USB-C ports plus an HDMI 2.0 output up to 4Kp60, and the host laptop can be charged at up to 100 W. USB 3.2 Gen 1 device speed is available when the unit is extended with an INOGENI U-BRIDGE 3.

Full specifications Datasheet Compare alternatives

In the box: 1x PC HOST extender module; 1x DEVICE extender module; 1x 1.8 m (6 ft) USB Type-C to Type-C cable; 1x 0.9 m (3 ft) micro-USB to USB-A cable; 1x Quick Start Guide; 2x mounting brackets for the power supply; 2x mounting brackets for the USB-C power supply; 2x mounting brackets for the PC HOST module; 2x mounting brackets for the DEVICE module; 16x black wooden screws; 1x power supply 100-240 V AC input, 24 V 2.5 A DC output; 1x USB-C power supply 100-240 V AC input, up to 20 V 5 A DC output; international power adapter with country-specific cord (North America, EU, UK, Australia/NZ or Japan)

Call 020 3815 8642

Key features

Full USB-C extension

Extends USB 2.0, power and DisplayPort Alternate Mode over a single CAT6A U/FTP cable using HDBaseT 3.0.

Reach

Up to 70 m (230 ft) at HDMI 4K30 and up to 40 m (132 ft) at HDMI 4K60.

100 W laptop charging

The PC HOST module charges the connected laptop through the provided USB-C power supply (up to 20 V 5 A).

Device-side ports and video output

2x USB-A (USB 3.2 Gen 1) and 1x USB-C (USB 3.2 Gen 1) receptacles, 1x USB-C DP Alt Mode source and 1x HDMI 2.0 output up to 3840x2160p60 / 4096x2160p60 with cable locking.

LAN and control

10/100 Mbps IP interface with DHCP or static addressing, used for control and for USB-C network connectivity over the PC HOST module. INOGENI note network connectivity is supported on Windows and Linux but not on macOS in this hardware revision.

Technical specifications

Choose a section to view its specifications.

Connectivity (4)

USB Speeds: USB 2.0 up to 480 Mbps for extended USB devices; USB 3.2 Gen 1 when extended with an INOGENI U-BRIDGE 3
PC Host Connectors: 1x USB Type-C host receptacle (video up to 3840x2160p60/4096x2160p60), 1x USB Type-C for the USB-C power supply, 1x RJ45, 1x USB-A USB3-EXT connector
Device Connectors: 2x USB-A (USB 3.2 Gen 1), 1x USB-C (USB 3.2 Gen 1), 1x USB-C DP Alt Mode source, 1x HDMI 2.0 output, 1x RJ45, 1x USB-B USB3-EXT connector
HDCP / HDMI Compliance: HDCP 2.3, 2.2 and 1.4; HDMI 2.0b, HDMI 1.4 and DVI 1.0; 600 MHz sampling

Power & Physical (5)

PC Host Dimensions: 12.0 cm x 14.0 cm x 3.3 cm (4.72" x 5.51" x 1.18"), 470 g (1.04 lb)
Device Dimensions: 22.3 cm x 14.0 cm x 3.3 cm (8.78" x 5.51" x 1.18"), 820 g (1.81 lb)
Enclosure Material: Aluminium/metal case
Package Dimensions: 35.5 cm x 29.0 cm x 12.6 cm (14.0" x 11.4" x 4.96")
Package Weight: 3610 g (9.96 lb)

Certifications & Warranty (1)

Certifications: Device: FCC, CE, UKCA, RoHS, SoV, RCM, NOM. Power supply 60 W: FCC, CE, UKCA, CB, UL, TUV, EMC, IEC62368, BIS. Power supply 100 W: FCC, CE, UKCA

General (9)

In the box: 1x PC HOST extender module; 1x DEVICE extender module; 1x 1.8 m (6 ft) USB Type-C to Type-C cable; 1x 0.9 m (3 ft) micro-USB to USB-A cable; 1x Quick Start Guide; 2x mounting brackets for the power supply; 2x mounting brackets for the USB-C power supply; 2x mounting brackets for the PC HOST module; 2x mounting brackets for the DEVICE module; 16x black wooden screws; 1x power supply 100-240 V AC in
Link Technology: HDBaseT 3.0 over CAT6A U/FTP
Range: Up to 70 m (230 ft) at HDMI 4K30; up to 40 m (132 ft) at HDMI 4K60
Available Current (Device): USB-A: 900 mA per port; USB-C: 3 A
IP Interface: 10/100 Mbps; DHCP or static addressing
Power Supplies: 100-240 V AC input, 24 V 2.5 A DC output; plus 100-240 V AC input USB-C up to 20 V 5 A DC output
Operating Temperature: 0 C to 50 C (32 F to 122 F)
TAA Compliant: Yes
Origin: Canada
