Home / Extenders / INOGENI U-BRIDGE 3 USB 3.2 Gen 1 Camera and Device Extender over CAT6A

INOGENI

INOGENI U-BRIDGE 3 USB 3.2 Gen 1 Camera and Device Extender over CAT6A

Name: INOGENI U-BRIDGE 3 USB 3.2 Gen 1 Camera and Device Extender over CAT6A
Brand: INOGENI
SKU: U-BRIDGE-3
Price: 841.20 GBP
Availability: OutOfStock

£841.20inc. VAT

£701.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £280.40 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

5 Years Warranty Included

Key specifications

In the box1x PC Host extender module; 1x Device extender module; 1x USB 3.0 Type-C to Type-C cable; 1x USB 2.0 mini-B cable; 1x Quick Start Guide; 2x mounting brackets (power supply); 2x mounting clips; 2x terminal blocks; 4x black wood screws; 1x power supply 100-240 V AC input, 24 V 1.5 A DC output; international power adapter with country-specific cord (North America, EU, UK, Australia/NZ or Japan)

Link TechnologyHDBaseT-USB3 over CAT6A U/FTP

RangeUp to 100 m (330 ft)

USB SpeedsUSB 3.2 Gen 1 / USB 3.1 Gen 1 / USB 3.0 up to 5 Gbps; USB 2.0 up to 480 Mbps. USB-C DisplayPort Alternate Mode is not supported

Transfer SupportBulk, isochronous, interrupt and control types, with built-in hardware acceleration for isochronous and bulk transfers

PC Host Connectors1x USB Type-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough

Device Connectors2x USB-A receptacles, 1x USB-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough

Available CurrentUp to 1.8 A shared between ports

All 19 specifications

Description

The INOGENI U-BRIDGE 3 is a multi-device extender that enables SuperSpeed USB 3.0 connections up to 100 m / 330 ft over a single CAT6A U/FTP cable using HDBaseT-USB3. The PC HOST module presents a lockable USB-C connector, while the DEVICE module offers two USB-A ports and one USB-C port with up to 1.8 A shared between them. RS-232 is passed through for VISCA or control, and either module can supply the power.

Full specifications Datasheet Compare alternatives

In the box: 1x PC Host extender module; 1x Device extender module; 1x USB 3.0 Type-C to Type-C cable; 1x USB 2.0 mini-B cable; 1x Quick Start Guide; 2x mounting brackets (power supply); 2x mounting clips; 2x terminal blocks; 4x black wood screws; 1x power supply 100-240 V AC input, 24 V 1.5 A DC output; international power adapter with country-specific cord (North America, EU, UK, Australia/NZ or Japan)

Key features

100 m SuperSpeed extension

HDBaseT-USB3 over a single CAT6A U/FTP cable, up to 100 m (330 ft); USB 3.2 Gen 1 up to 5 Gbps, backward compatible with USB 3.1 Gen 1, 3.0 and 2.0.

Three device ports

DEVICE module provides 2x USB-A receptacles and 1x USB-C receptacle with mounting screw hole, up to 1.8 A shared between ports.

Lockable USB-C host connection

PC HOST module has 1x USB Type-C receptacle with a mounting screw hole.

RS-232 passthrough

Passthrough serial connection on both modules for VISCA or control.

Flexible powering and mounting

24 V 1.5 A supply applied at either the PC HOST or DEVICE module; brackets provided, black anodised aluminium cases.

Technical specifications

Choose a section to view its specifications.

Connectivity (5)

USB Speeds: USB 3.2 Gen 1 / USB 3.1 Gen 1 / USB 3.0 up to 5 Gbps; USB 2.0 up to 480 Mbps. USB-C DisplayPort Alternate Mode is not supported
Transfer Support: Bulk, isochronous, interrupt and control types, with built-in hardware acceleration for isochronous and bulk transfers
PC Host Connectors: 1x USB Type-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough
Device Connectors: 2x USB-A receptacles, 1x USB-C receptacle with mounting screw hole, 1x RJ45, RS-232 passthrough
Consumed USB Tiers: Up to 2 tiers

Power & Physical (5)

PC Host Dimensions: 7.0 cm x 9.7 cm x 2.3 cm (2.76" x 3.82" x 0.90"), 170 g (0.37 lb)
Device Dimensions: 7.0 cm x 13.7 cm x 2.3 cm (2.76" x 5.39" x 0.90"), 210 g (0.46 lb)
Enclosure Material: Black anodised aluminium case
Package Dimensions: 24.5 cm x 25 cm x 7.9 cm
Package Weight: 1200 g (2.65 lb)

Certifications & Warranty (1)

Certifications: Device: FCC, CE, UKCA, RoHS, IEC62368, SoV, RCM, NOM. Power supply 36 W: FCC, CE, UKCA, CB, UL, TUV, EMC

General (8)

In the box: 1x PC Host extender module; 1x Device extender module; 1x USB 3.0 Type-C to Type-C cable; 1x USB 2.0 mini-B cable; 1x Quick Start Guide; 2x mounting brackets (power supply); 2x mounting clips; 2x terminal blocks; 4x black wood screws; 1x power supply 100-240 V AC input, 24 V 1.5 A DC output; international power adapter with country-specific cord (North America, EU, UK, Australia/NZ or Japan)
Link Technology: HDBaseT-USB3 over CAT6A U/FTP
Range: Up to 100 m (330 ft)
Available Current: Up to 1.8 A shared between ports
Power Supply: 100-240 V AC input, 24 V 1.5 A DC output; applied at either PC HOST or DEVICE module
Operating Temperature: 0 C to 50 C (32 F to 122 F)
TAA Compliant: Yes
Origin: Canada

Documents

INOGENI U-BRIDGE 3 USB 3.2 Gen 1 Camera and Device Extender over CAT6A datasheet
