Home / Rack Units / Excel Elevate DCR600 42U Rack 600 x 1200 mm Vented (F) D/Vented (R) B/Panels Network Black

Excel

Excel Elevate DCR600 42U Rack 600 x 1200 mm Vented (F) D/Vented (R) B/Panels Network Black

Name: Excel Elevate DCR600 42U Rack 600 x 1200 mm Vented (F) D/Vented (R) B/Panels Network Black
Brand: Excel
SKU: 546-42612-VDBF-BK
Price: 2863.20 GBP
Availability: OutOfStock

£2,863.20inc. VAT

£2,386.00 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

Key specifications

Number of rack units (RU)42

Width600 mm

Height2000 mm

Depth1200 mm

Modular spacing19 inch

Max. load capacity2000 kg

Number of doors2

With front dooryes

All 25 specifications

Description

Elevate DCR Series Network Model with Vented Front Door, Double Vented Rear Doors, both side panels and Front Cable Management. The new Elevate data centre racks are a versatile range of 600 mm or 800 mm wide racks designed for the data centre market and based on our successful, market accepted Excel Rack design. The new DCR series feature the same flexibility of options and configuration with higher airflow mesh doors, airflow management baffles at the front, finger style cable management and upgraded manual or optional electronic handles. There is also improved cable access with full depth wide brush strips on the roof, cabinet to cabinet cable routing via side brush openings and multiple brush entry through the airflow management baffles. Manufacturer part number 546-42612-VDBF-BK.

Full specifications Compare alternatives

Call 020 3815 8642

Key features

Feature

Available in 42U, 47U and 52U sizes

Feature

High ventilation flat mesh doors front and back

Feature

Airflow management baffles as standard with cable management

Feature

Entry/exit points in roof compatible with 16A, 32A and 64A EN60309 Commando plugs

Feature

Upgraded cable tray fitted both sides

Technical specifications

Choose a section to view its specifications.

Display (1)

Side panels included: yes

Power & Physical (8)

Width: 600 mm
Height: 2000 mm
Depth: 1200 mm
Front door material: Steel
Rear door material: Steel
Mounting Profile: Front and rear
Material: Steel
Colour: Black

General (16)

Number of rack units (RU): 42
Modular spacing: 19 inch
Max. load capacity: 2000 kg
Number of doors: 2
With front door: yes
Front door locking system: Two-point
With rear door: yes
Rear door locking system: Three-point
Type of profile rail: L-shaped
Type of ventilation: Passive
With vertical cable management: no
With roof plate: yes
With earthing: yes
Type of surface: Powder coated
RAL-number: 9004
Flat-packed: no
