Home / Amplifiers / Crestron AMP-X75 X-Series 75 W Amplifier

Crestron

Crestron AMP-X75 X-Series 75 W Amplifier

Name: Crestron AMP-X75 X-Series 75 W Amplifier
Brand: Crestron
SKU: AMP-X75
Price: 673.13 GBP
Availability: OutOfStock

£673.13inc. VAT

£560.94 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £224.38 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Output power (LoZ)2 x 35 W into 8 or 4 ohms single-ended; 75 W bridged into 8 ohms

Output power (Hi-Z)75 W at 70V or 100V

Input signal typeBalanced or unbalanced analogue line-level

Frequency response20 Hz to 20 kHz +/-0.5 dB at 1 W

THD+N<0.1% at 1 kHz at -3 dB full rated output power

Signal-to-noise ratio>103 dBA, 20 Hz to 20 kHz, balanced

Crosstalk-75 dB at 1 kHz

Gain23 dB at 8 ohms, balanced input

All 15 specifications

Description

A quarter-rack Class D amplifier that switches between low-impedance stereo and 70V/100V distributed operation without extra hardware.

Full specifications Datasheet Compare alternatives

The same amplifier drives a pair of 8 ohm speakers, a single bridged 75 W channel, or a 70V/100V distributed line, so one part number covers most small commercial audio jobs. Rack, surface and ganging hardware all ship in the box. Units stack vertically in a rack without extra ventilation space because the design is convection cooled rather than fan cooled.

Shorted or overloaded speaker lines, excessive input and overheating all mute the outputs until the fault clears, and a prolonged internal fault shuts the amplifier down instantly. With no input signal for 25 minutes the amplifier drops to 0.41 W standby and wakes in about a tenth of a second when audio returns; a contact-closure remote input can force standby too. Specifications on this page are taken from Crestron's published documentation for this part number.

Key features

Low or high impedance from one box

The same amplifier drives a pair of 8 ohm speakers, a single bridged 75 W channel, or a 70V/100V distributed line, so one part number covers most small commercial audio jobs.

Quarter-rack modular chassis

Rack, surface and ganging hardware all ship in the box. Units stack vertically in a rack without extra ventilation space because the design is convection cooled rather than fan cooled.

Protected against real-world faults

Shorted or overloaded speaker lines, excessive input and overheating all mute the outputs until the fault clears, and a prolonged internal fault shuts the amplifier down instantly.

Sleeps when the room does

With no input signal for 25 minutes the amplifier drops to 0.41 W standby and wakes in about a tenth of a second when audio returns; a contact-closure remote input can force standby too.

Technical specifications

Connectivity

Output power (LoZ)2 x 35 W into 8 or 4 ohms single-ended; 75 W bridged into 8 ohms

Output power (Hi-Z)75 W at 70V or 100V

Input signal typeBalanced or unbalanced analogue line-level

Speaker output(1) 4-pin 5.08 mm pitch plug with screw locking retainers, accepts up to 12 AWG

Power & Physical

Dimensions (H x W x D)1.75 x 4.33 x 8.78 in. (44 x 110 x 223 mm) without brackets

General

Frequency response20 Hz to 20 kHz +/-0.5 dB at 1 W

THD+N<0.1% at 1 kHz at -3 dB full rated output power

Signal-to-noise ratio>103 dBA, 20 Hz to 20 kHz, balanced

Crosstalk-75 dB at 1 kHz

Gain23 dB at 8 ohms, balanced input

High-pass filter-3 dB at 80 Hz, -12 dB/octave (70V and 100V operation only)

ProtectionClipping, over current, under voltage, over temperature, DC offset, extreme high frequency

StandbyAutomatic after 25 minutes with no signal; 0.1 s typical wake time

Power100-240VAC 50/60 Hz, 370-200 mA; 0.41 W in standby

CoolingConvection cooled, fanless metal chassis

Documents

Crestron AMP-X75 spec sheet (PDF) - X-Series 75 W amplifier.
