Home / Amplifiers / Crestron AMP-X300 X-Series Amplifier, 300 W

Crestron

Crestron AMP-X300 X-Series Amplifier, 300 W

Name: Crestron AMP-X300 X-Series Amplifier, 300 W
Brand: Crestron
SKU: AMP-X300
Price: 623.18 GBP
Availability: OutOfStock

£623.18inc. VAT

£519.32 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £207.73 with PayPal Pay in 3.

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

3 Years Warranty Included

Key specifications

Input Signal TypesBalanced or unbalanced analogue line-level

Output PowerTotal output from all channels combined up to 300 W; 150 W per channel LoZ 8 ohm, 300 W bridged 8 ohm, 300 W at 70V or 100V

Frequency Response20 Hz to 20 kHz +/-0.5 dB at 1 W

THD+N<0.1% at 1 kHz at -3 dB full rated output power

S/N Ratio>103 dBA, 20 Hz to 20 kHz, balanced

Input Sensitivity1.23 Vrms, +4 dBu balanced; 0.316 Vrms, -10 dBV unbalanced

Gain29 dB at 8 ohms

High-Pass Filter-3 dB at 80 Hz, -12 dB/octave (70V and 100V operation only)

All 15 specifications

Description

A fanless four-channel installation amplifier that can be configured for low-impedance, bridged or 70V/100V line operation up to 300 W total, in a half-rack 1U chassis.

Full specifications Datasheet Compare alternatives

A front slide switch moves the unit between 4/8 ohm operation and 70V/100V distributed lines, so the same stock item covers a boardroom pair of speakers or a ceiling-speaker run. Convection cooling with no fan means it can live in a credenza or an occupied room without adding noise to a space that was meant to be quiet.

It stands alone, surface mounts, or ganges with other Crestron modular AMP units into a 1U 19 in. rack space, which suits small racks and under-table mounts. Power Saver mode drops to well under a watt after 25 minutes without signal and wakes in about half a second, so idle rooms are not burning power. Specifications on this page are taken from Crestron's published documentation for this part number.

Key features

One amplifier for low-impedance or 100V lines

A front slide switch moves the unit between 4/8 ohm operation and 70V/100V distributed lines, so the same stock item covers a boardroom pair of speakers or a ceiling-speaker run.

Silent by design

Convection cooling with no fan means it can live in a credenza or an occupied room without adding noise to a space that was meant to be quiet.

Half-width, gangable, rackable

It stands alone, surface mounts, or ganges with other Crestron modular AMP units into a 1U 19 in. rack space, which suits small racks and under-table mounts.

Sensible standby behaviour

Power Saver mode drops to well under a watt after 25 minutes without signal and wakes in about half a second, so idle rooms are not burning power.

Technical specifications

Choose a section to view its specifications.

Connectivity (5)

Input Signal Types: Balanced or unbalanced analogue line-level
Output Power: Total output from all channels combined up to 300 W; 150 W per channel LoZ 8 ohm, 300 W bridged 8 ohm, 300 W at 70V or 100V
Input Sensitivity: 1.23 Vrms, +4 dBu balanced; 0.316 Vrms, -10 dBV unbalanced
Speaker Outputs: (2) 4-pin 5.08 mm pitch 12A plugs with screw locking retainers; terminals accept up to 12 AWG (3.31 mm2)
Audio Inputs: (4) RCA unbalanced line-level inputs and (4) 3-pin 3.5 mm balanced line-level inputs

Power & Physical (2)

Power Consumption: 75 W with four channels driven at 1/8 output power into 4 ohms; 16 W idle in Hi-Z mode; 0.365 W in power saver
Dimensions: Height 1.75 in. (44 mm) without feet; Width 8.67 in. (220 mm) without brackets, 19.00 in. (483 mm) with brackets; Depth 11.04 in. (280 mm)

General (8)

Frequency Response: 20 Hz to 20 kHz +/-0.5 dB at 1 W
THD+N: <0.1% at 1 kHz at -3 dB full rated output power
S/N Ratio: >103 dBA, 20 Hz to 20 kHz, balanced
Gain: 29 dB at 8 ohms
High-Pass Filter: -3 dB at 80 Hz, -12 dB/octave (70V and 100V operation only)
Protection: Over current, under voltage, over temperature, DC offset, extreme high frequency
Main Power: 1.2-0.6A at 100-240VAC, 50/60 Hz via IEC 60320 C14 inlet
Chassis: Metal, convection cooled (fanless), black finish

Documents

Crestron AMP-X300 spec sheet (PDF) - X-Series 300 W amplifier.
