Chief XCB1U Fusion Extra-Large Single Pole Back-to-Back Ceiling Mount

Name: Chief XCB1U Fusion Extra-Large Single Pole Back-to-Back Ceiling Mount
Brand: Chief
SKU: XCB1U
Price: 688.80 GBP
Availability: OutOfStock

£688.80inc. VAT

£574.00 ex. VAT

Out of stock

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

10 Years Warranty Included

Key specifications

Weight capacity90.7 kg

VESA mounting pattern200 x 100mm - 800 x 400mm

Number of displays2

Tilt+/- 5 (to -20 for screens up to 38.8in tall)

AdjustabilityTilt

ApplicationCeiling

Interface includedYes

OrientationLandscape

All 15 specifications

Description

The XCB1U is the ceiling head from Chief's Fusion extra-large range, configured to carry two displays back to back on one pole. It is built for digital signage in concourses, retail and transport interchanges where the message has to face both directions from a single drop.

Full specifications Datasheet Compare alternatives

Continuous tilt with four set locking points makes it straightforward to bring several screens in a run to the same angle, and Centris fingertip tilt means that angle can be set by hand rather than by wrench. The head swivels to any viewing angle, screens engage without tools, and a padlock can be added for security. Post-installation levelling roll takes out residual twist.

Interface brackets are included and the head takes VESA patterns from 200 x 100 mm up to 800 x 400 mm at a rated 90.7 kg. Tilt is plus or minus 5 degrees, extending to minus 20 degrees for screens up to 985 mm tall. A ceiling plate and extension column are required and are ordered separately; the head fits both traditional 1.5 inch NPT and Chief's CPA pinned column systems. TAA compliant and UL Listed. Supplied by TopAV. Manufacturer part number XCB1U.

Key features

Weight capacity

Rated to 90.7 kg (200 lb).

Two displays back to back

Single-pole head carrying a pair of extra-large screens facing opposite directions.

VESA range

200 x 100 mm to 800 x 400 mm, with interface brackets included.

Repeatable tilt

Plus or minus 5 degrees, to minus 20 degrees for screens up to 985 mm tall, with four set locking points.

Column compatibility

Fits 1.5 inch NPT and Chief CPA pinned columns; ceiling plate and column ordered separately.

TAA compliant and UL Listed

Certified TAA and UL Listed, with post-installation levelling roll.

Technical specifications

Display

Number of displays2

Power & Physical

Weight capacity90.7 kg

VESA mounting pattern200 x 100mm - 800 x 400mm

ColourBlack

Shipping dimensions94.0 x 36.8 x 27.9 cm

Shipping weight20 kg

Certifications & Warranty

CertificationsTAA, UL Listed

General

Tilt+/- 5 (to -20 for screens up to 38.8in tall)

AdjustabilityTilt

ApplicationCeiling

Interface includedYes

OrientationLandscape

Post-installation levelling rollYes

Column interface1.5in NPT and Chief CPA pinned columns

TAA compliantYes

Documents

Chief XCB1U installation manual (PDF, Legrand AV). Attached in place of the cutsheet, which Legrand generates in the browser rather than hosting.
