Home / Projector Mounts / Chief VCTUB Extra-Large Universal Tool-Free Projector Mount - Black

Chief

Chief VCTUB Extra-Large Universal Tool-Free Projector Mount - Black

Name: Chief VCTUB Extra-Large Universal Tool-Free Projector Mount - Black
Brand: Chief
SKU: VCTUB
Price: 470.40 GBP
Availability: OutOfStock

£470.40inc. VAT

£392.00 ex. VAT

Out of stock

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

10 Years Warranty Included

Key specifications

Shipping Dimensions530.7 x 484.9 x 180.1 mm

Shipping Weight14.2 kg

Weight Capacity68 kg

AdjustabilityIndependent Roll-Pitch-Yaw, Micro-Adjustable

AdjustmentsMicro Roll 5°, Micro Pitch 20°, Micro Yaw 10° and Macro Yaw 360°

ApplicationCeiling

ColourBlack

Interface TypeUniversal

All 13 specifications

Description

The Chief VCTUB is an extra-large universal ceiling projector mount rated to 150 lbs (68 kg), aimed at the 50-150 lb laser projectors now common in auditoriums and large lecture spaces. It is lighter and slimmer than the VCM range it succeeds while carrying a comparable load.

Full specifications Datasheet Compare alternatives

Registration is tool-free. MicroZone adjustment gives micro roll of 5 degrees, micro pitch of 20 degrees and micro yaw of 10 degrees, on top of 360 degrees of macro yaw, so an installer can dial the image in from the ladder without reaching for a spanner and can return to it later without disturbing the mounting hardware.

Adjustable interface arms accommodate a wide range of projector mounting-hole patterns rather than a single chassis. The mount ships at 31.38 lbs (14.2 kg), is finished in black and is UL Listed.

Supplied by TopAV. Manufacturer part number VCTUB.

Key features

Weight capacity 150 lbs (68 kg)

Rated for large-venue projector bodies; verify against your projector's published weight before ordering.

Tool-free MicroZone adjustment

Roll, pitch and yaw are set by hand without tools, so image registration can be completed and revisited from the ladder.

Adjustment range

Micro roll 5 degrees, micro pitch 20 degrees, micro yaw 10 degrees, plus 360 degrees of macro yaw.

Universal projector interface

Adjustable arms fit a wide range of projector mounting patterns rather than one specific chassis.

Slimmer than the VCM it succeeds

Lower profile and lighter than Chief's earlier VCM heavy-duty mount at a comparable load class.

UL Listed

Independently safety certified; shipping weight 31.38 lbs (14.2 kg).

Technical specifications

Power & Physical

Shipping Dimensions530.7 x 484.9 x 180.1 mm

Shipping Weight14.2 kg

Weight Capacity68 kg

ColourBlack

Certifications & Warranty

CertificationsUL Listed

General

AdjustabilityIndependent Roll-Pitch-Yaw, Micro-Adjustable

AdjustmentsMicro Roll 5°, Micro Pitch 20°, Micro Yaw 10° and Macro Yaw 360°

ApplicationCeiling

Interface TypeUniversal

Protective GlassNo

Solution TypeUniversal

Special FeaturesLarge Venue

TAA CompliantNo

Documents

Chief VCTU series cutsheet / specification sheet (PDF).
