Home / Fixed Wall Mounts / Chief ODMLA25 Articulating Outdoor Wall Mount
Chief

Chief ODMLA25 Articulating Outdoor Wall Mount

£696.00inc. VAT
£580.00 ex. VAT
Out of stock
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
10 Years Warranty Included
Key specifications
Weight capacity68 kg
Typical screen size32 - 80 in
VESA mounting pattern75 x 75mm - 709 x 444mm
Tilt+15 / -15
AdjustabilityExtension, swivel, tilt
Overall dimensions470 x 748 x 124 mm
Depth12.4 cm
Height47 cm
All 15 specifications

Description

The ODMLA25 is built for all-weather outdoor installation, with outdoor-rated finishing and stainless steel hardware throughout. It suits outdoor digital signage, covered outdoor living areas and humid indoor spaces such as pool halls and wash-down environments, and works with indoor or outdoor displays alike.

Full specifications Datasheet Compare alternatives

The articulating arm swings the screen out from the wall and swivels it to any viewing angle, with plus or minus 15 degrees of tilt on top. Folded back the mount sits 124 mm deep. The wall plate is 470 mm high by 748 mm wide and takes displays from 32 to 80 inches on VESA patterns between 75 x 75 mm and 709 x 444 mm, up to 68 kg.

It can be fixed to a bare 200 mm concrete wall if 8 x 76 mm Buildex Tapcon anchors with Blue Climaseal coating are used in place of the lag bolts supplied; those anchors are not included. Supplied by TopAV. Manufacturer part number ODMLA25.

Key features

Weight capacity

Rated to 68 kg (150 lb).

Screen size range

Suits displays from 32 to 80 inches.

VESA range

75 x 75 mm to 709 x 444 mm.

Full motion

Extension, swivel and plus or minus 15 degrees of tilt, folding back to 124 mm deep.

Built for outdoors

Outdoor-rated finish and stainless steel hardware for all-weather and humid installations.

Concrete fixing option

Mounts to bare 200 mm concrete using Tapcon anchors with Climaseal coating, supplied separately.

Technical specifications

Display
Typical screen size32 - 80 in
Power & Physical
Weight capacity68 kg
VESA mounting pattern75 x 75mm - 709 x 444mm
Overall dimensions470 x 748 x 124 mm
Depth12.4 cm
Height47 cm
Width74.8 cm
Minimum depth12.4 cm
ColourBlack
Shipping weight19.1 kg
General
Tilt+15 / -15
AdjustabilityExtension, swivel, tilt
OrientationLandscape
ApplicationWall, outdoor
TAA compliantNo

Documents

Chief ODMLA25 installation manual (PDF, Legrand AV). Attached in place of the cutsheet, which Legrand generates in the browser rather than hosting.
