Chief LDB1U Large Fusion Bolt-Down Table Stand - Black

Name: Chief LDB1U Large Fusion Bolt-Down Table Stand - Black
Brand: Chief
SKU: LDB1U
Price: 566.40 GBP
Availability: OutOfStock

£566.40inc. VAT

£472.00 ex. VAT

Out of stock

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

10 Years Warranty Included

Key specifications

ColourBlack

Typical screen size46 - 70 in

Weight capacity56.7 kg

VESA mounting pattern100 x 100mm - 642 x 400mm

Equipment height range560 - 965 mm

AdjustabilitySwivel

Swivel range+/- 15 or 30 degrees

Mounting methodBolt-down table stand

All 12 specifications

Description

The LDB1U is the bolt-down member of Chief's Fusion table stand pair. Instead of resting on a base plate it fixes through the worksurface, which suits fixed installations, medical carts and public-facing desks where the display must not be lifted or moved. It carries a 46" to 70" screen weighing up to 56.7 kg.The column swivels by hand and rotation limits can be set at plus or minus 15 or 30 degrees to stop the screen striking a wall or partition behind it. Cabling runs through a wide channel inside the column. Equipment height sits between 560 mm and 965 mm.The built-in universal interface covers VESA patterns from 100 x 100 mm to 642 x 400 mm, so no separate adapter plate is needed for most commercial panels. The free-standing LDS1U is the same stand on a weighted base.Supplied by TopAV. Manufacturer part number LDB1U.

Full specifications Datasheet Compare alternatives

Key features

46-70" displays up to 56.7 kg

Rated for a single display from 46" to 70" diagonal with a 125 lb (56.7 kg) capacity.

Bolt-down through the worksurface

Fixes into the table rather than resting on it, for installations where the screen must stay put.

Limited swivel

Rotation stops can be set at plus or minus 15 or 30 degrees.

Built-in universal interface

Covers VESA patterns from 100 x 100 mm through to 642 x 400 mm.

In-column cable channel

A wide internal channel conceals the cable run.

560-965 mm equipment height

Sets the working height of the mounted display above the table.

Technical specifications

Display

Typical screen size46 - 70 in

Power & Physical

ColourBlack

Weight capacity56.7 kg

VESA mounting pattern100 x 100mm - 642 x 400mm

Equipment height range560 - 965 mm

Mounting methodBolt-down table stand

Shipping dimensions851 x 426 x 143 mm

Shipping weight11.3 kg

General

AdjustabilitySwivel

Swivel range+/- 15 or 30 degrees

OrientationLandscape

TAA compliantNo

Documents

Chief LDS1U and LDB1U specification sheet (PDF cutsheet) from Legrand AV.
