Home / Floor-to-Wall Stands / Chief FMSFC Fusion Modular Bolt-Down Column
Chief

Chief FMSFC Fusion Modular Bolt-Down Column

£812.40inc. VAT
£677.00 ex. VAT
Out of stock
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Installation services availablePurchase orders: education customers only
10 Years Warranty Included
Key specifications
Weight Capacity227 kg
Typical Screen Size42 - 65 in
VESA Mounting Pattern400mm for landscape and 800mm for portrait
AdjustabilityFixed
Manual Height AdjustmentMicro-adjustment up to 0.75" (19 mm) per screen
Lateral ShiftYes
Plumb AdjustmentMicro-adjustment up to 0.75" (19 mm)
Center of Display To Floor Table RangeMax center display height is 64.5" (164cm), These can be increased by 18" (46cm) or 36" (91cm) with extenders
All 19 specifications

Description

The Chief FMSFC is a bolt-down column for Chief’s Fusion modular system, used to build permanent freestanding video walls and display arrays where there is no wall to work with. Bolting to the floor rather than relying on a weighted base gives a permanent, low-footprint installation.

Full specifications Datasheet Compare alternatives

The column stands 1686 mm tall on a 203 x 203 mm section and is rated to 227 kg. It carries displays of 42 to 65 in, using a 400 mm pattern for landscape screens and 800 mm for portrait. Maximum centre-of-display height is 1640 mm, which can be raised by 460 mm or 910 mm with extenders.

Because it is modular, multiple columns combine to form wider arrays, and the system offers lateral shift plus micro-adjustment of up to 19 mm per screen for both height and plumb, so panels can be aligned precisely after assembly. Cable management runs inside the column. The unit is finished in black and is TAA compliant.

Supplied by TopAV. Manufacturer part number FMSFC.

Key features

227 kg weight capacity

Rated to 500 lbs (227 kg).

Bolt-down permanent installation

Fixes to the floor for a permanent freestanding video wall or display array.

1686 mm column height

203 x 203 mm section; maximum centre-of-display height 1640 mm, extendable by 460 mm or 910 mm.

42-65 in displays

Uses a 400 mm pattern for landscape screens and 800 mm for portrait.

19 mm micro-adjustment

Lateral shift plus height and plumb micro-adjustment of up to 0.75 in per screen.

Integrated cable management

Cabling runs inside the column; multiple columns combine into wider arrays.

Technical specifications

Display
Typical Screen Size42 - 65 in
Center of Display To Floor Table RangeMax center display height is 64.5" (164cm), These can be increased by 18" (46cm) or 36" (91cm) with extenders
Power & Physical
Weight Capacity227 kg
VESA Mounting Pattern400mm for landscape and 800mm for portrait
Manual Height AdjustmentMicro-adjustment up to 0.75" (19 mm) per screen
ColourBlack
Overall Dimensions66.38" x 8" x 8" (1686 x 203 x 203mm)
Depth20.3 cm
Height168.6 cm
Width20.3 cm
Shipping Weight12.3 kg
Certifications & Warranty
CertificationsTAA
General
AdjustabilityFixed
Lateral ShiftYes
Plumb AdjustmentMicro-adjustment up to 0.75" (19 mm)
OrientationLandscape
Solution TypeUniversal
Special FeaturesModular, Multi-Display
TAA CompliantYes

Documents

Chief FMSFC installation manual (PDF). Chief generates its cutsheet in the browser and publishes no downloadable version.
