Chief DVM0500U3E TiLED dvLED Universal 500mm Wall Mount - 3 High Extender

The DVM0500U3E is a direct-view LED extender rather than an LCD bracket. It stacks above a TiLED Universal starter mount to add three more 500 mm-tall dvLED cabinets to the same column. TiLED walls are built from the bottom up: the starter carries the load and every extender above it works within that column's rating.

Adjustment matches the rest of the range - 17 mm of lateral shift, up to 50.8 mm of height adjustment and micro depth adjustment - so cabinets added higher up the wall land in pixel alignment with the row below. Floating button-capture hardware and the included M6 and M8 button kits suit interlocking cabinets from most leading dvLED manufacturers.

The extender sits 51 mm deep and needs a plywood-reinforced wall. It is TAA compliant. Order it alongside a matching starter - it is not a standalone mount. Supplied by TopAV. Manufacturer part number DVM0500U3E.
