Biamp
Biamp TesiraLUX IDH-1
£2,227.20inc. VAT
£1,856.00 ex. VAT
Out of stock
1
- Visa
- Mastercard
- American Express
- PayPal
Seen it cheaper? We price-match genuine like-for-like quotes. How it works
Bought in the UK, backed in the UKWhy it matters →
- Sourced through UK distribution
- UK manufacturer warranty
- UK-based engineers
- No import duty or customs charges
- GBP pricing, UK VAT invoices
5 Years Warranty Included
Key specifications
Primary ApplicationSight and Sound Reinforcement
Height1.75 inches (44 mm)
Width8.5 inches (216 mm)
Depth10.4 inches (264 mm)
Weight4 lbs (1.8 kg)
PowerCurrent Draw (100-240VAC 50/60Hz): 0.5-0.21A
Phantom Power+48 VDC (7mA/input)
Current Draw(100-240VAC 50/60Hz) = 0.5-0.21A
Description
The TesiraLUX IDH-1 is an AVB/TSN enabled video encoder capable of transmitting video signals up to and including 4K60. The IDH-1 functions as a video server-class device in a Tesira media system and is configured through the Tesira configuration software.
Acting as an AVB talker, the IDH-1 fully integrates digital audio and video on a single network, allowing for simplified lip sync management and end-to-end network transit latencies of less than 1.5 frames. Multiple software-based options are available for managing bandwidth, including setting maximum resolution, frame rate floor, and/or a rate of compression. The AVB/TSN streams can be transmitted over 1Gb or 10Gb ports while control signals are managed via a separate 1Gb Ethernet port. The IDH-1 accepts 8 channels of PCM audio for embedding/de-embedding, and includes 2 mic/line level analog inputs.
The TesiraLUX IDH-1 can be used as a standalone device (paired with a TesiraLUX OH-1) or can be combined with other Tesira servers, expanders, endpoints, and controllers.
The complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.
Key features:
- Accepts video signals up to and include 4K60 with 4:4:4 subsampling Dynamic Delay EQ for automatic lip sync management
- Flexible software configurable bandwidth controls
- Supports eight-channel PCM audio for embedding/de-embedding
- Includes one HDMI port and one Display Port 1.2. port
- Half-rack chassis
- Optional mounting accessories available
- 5-year warranty
- Compliant with the US Trade Agreement Act (TAA)
- Biamp Workplace Ready
Key features
Accepts video signals up to and include 4K60 with 4
Accepts video signals up to and include 4K60 with 4:4:4 subsampling Dynamic Delay EQ for automatic lip sync management
Flexible software configurable bandwidth controls
Flexible software configurable bandwidth controls
Supports eight-channel PCM audio for embedding/de-embedding
Supports eight-channel PCM audio for embedding/de-embedding
Includes one HDMI port and one Display Port 1.2. port
Includes one HDMI port and one Display Port 1.2. port
Half-rack chassis
Half-rack chassis
Optional mounting accessories available
Optional mounting accessories available
5-year warranty
5-year warranty
Compliant with the US Trade Agreement Act (TAA)
Compliant with the US Trade Agreement Act (TAA)
Technical specifications
Choose a section to view its specifications.
Display (1)
- Supported Resolution
- Up to 4K60
Connectivity (1)
- Network Transit Latency
- 1.5 frames (25ms @ 60fps)
Power & Physical (5)
- Height
- 1.75 inches (44 mm)
- Width
- 8.5 inches (216 mm)
- Depth
- 10.4 inches (264 mm)
- Weight
- 4 lbs (1.8 kg)
- Color Bit Depth
- 8-bit, 10-bit, 12-bit, 16-bit
Certifications & Warranty (1)
- Certifications
- FCC Part 15B (USA) UL and C-UL (USA and Canada) CE Marked (Europe) RoHS Directive (Europe)
General (17)
- Primary Application
- Sight and Sound Reinforcement
- Power
- Current Draw (100-240VAC 50/60Hz): 0.5-0.21A
- Phantom Power
- +48 VDC (7mA/input)
- Current Draw
- (100-240VAC 50/60Hz) = 0.5-0.21A
- Control
- RJ-45 with Ethernet cable (Cat 5e and above)
- TAA Compliant
- TAA Compliant
- Logic I/O
- Logic Input Trigger: Contact Closure or 5V TTL LED Driver: 5V/10mA per output Logic Output Type: Open Collector; Sink 40V/300mA per output
- 1 Gb
- RJ-45 with Ethernet cable (Cat 5e and above)
- RS-232
- 115200/8-N-1
- 10 Gb
- 10G fiber SFP+
- Ambient Operating Temperature Range
- 32 - 104° F (0 - 40° C)
- Humidity
- 0-95% relative humidity (non-condensing)
- Altitude
- 0-6,600 ft (0-2000m) MSL
- Physical Interfaces
- HDMI, DisplayPort
- Colorspace
- Up to Rec. 2020
- Color Formats
- YUV, RGB
- Chroma Sampling
- 4:4:4, 4:2:2, 4:2:0
