Home / Golf Simulator Projectors / BenQ AH700ST Full HD 4,000-Lumen Short Throw Golf Simulator Projector

BenQ

BenQ AH700ST Full HD 4,000-Lumen Short Throw Golf Simulator Projector

Name: BenQ AH700ST Full HD 4,000-Lumen Short Throw Golf Simulator Projector
Brand: BenQ
SKU: 9H.JST77.1HE
Price: 2002.48 GBP
Availability: OutOfStock

£2,002.48inc. VAT

£1,668.73 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Independently reviewed on Trustpilot

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 020 3815 8642

Return within 14 days

Installation services available Purchase orders: education customers only

Key specifications

Projection SystemDLP

Brightness4000 ANSI lumens

Native Aspect Ratio16:9

Screen Fill Ratios16:9, 16:10, 4:3, 1:1

Contrast Ratio (FOFO)3,000,000:1

Display Colour30-bit (1.07 billion colours)

Light Source Life20,000 h

Zoom Ratio1.2x

All 28 specifications

Description

BenQ builds the AH700ST specifically for golf simulator bays, and the specification reflects that rather than a general-purpose meeting room. A 0.69-0.83:1 short throw ratio fills a simulator screen from a ceiling position close enough that a player's swing does not cross the beam, and Screen Fill lets the 16:9 panel be mapped to 16:10, 4:3 or 1:1 to match the enclosure's impact screen.

Also in this range:5,500-Lumen 4,600-Lumen AH500ST 5,000-Lumen Full specifications Datasheet Compare alternatives

The laser light source is rated at 20,000 hours and delivers 4,000 ANSI lumens with a 3,000,000:1 contrast ratio and 95% Rec.709 coverage. A dedicated Golf picture mode sits alongside HDR10, HLG, Cinema and Game presets. Input lag is 16.7ms at 1080p 120Hz, which matters when the simulator software is drawing ball flight in real time.

Connections cover two HDMI 2.0b inputs with HDCP 2.2, USB Type-C with DisplayPort Alt Mode, two USB Type A ports (one for an optional wireless dongle) and RS232. HDMI eARC passes 7.1-channel audio to a simulator's sound system, and a 10W speaker covers rooms that do not have one. The unit is 303.5 x 112.4 x 234.5mm and 3.3kg.

Call 020 3815 8642

Key features

0.69-0.83:1 short throw

Fills a simulator screen from a ceiling mount close to the hitting area, keeping the projector out of the swing path.

Screen Fill for 16:10, 4:3 and 1:1

Maps the image to the impact screen's actual aspect ratio instead of leaving black bars in the enclosure.

Dedicated Golf picture mode

A factory preset tuned for simulator content, alongside HDR10, HLG, Cinema and Game modes and 95% Rec.709 coverage.

16.7ms input lag at 120Hz

Keeps ball-flight rendering in step with the shot, and HDMI eARC passes 7.1-channel audio to the bay's sound system.

Technical specifications

Choose a section to view its specifications.

Display (9)

Brightness: 4000 ANSI lumens
Native Aspect Ratio: 16:9
Screen Fill Ratios: 16:9, 16:10, 4:3, 1:1
Contrast Ratio (FOFO): 3,000,000:1
Display Colour: 30-bit (1.07 billion colours)
Resolution: 1080p (1920 x 1080)
Contrast Ratio: 3,000,000:1 (FOFO)
Aspect Ratio: 16:9
HDR Support: HDR10, HLG

Connectivity (3)

Input Lag: 16.7 ms (1080p 120Hz), 33.4 ms (1080p 60Hz)
White Light Output: 4,000 ANSI lumens
Connectivity: 2 x HDMI 2.0b (HDCP 2.2), USB-C (DisplayPort, 5V/1A PD out), 2 x USB-A, RS-232

Audio (1)

Audio: 1 x 10W speaker, eARC 7.1-channel HDMI audio return

Power & Physical (3)

Power Consumption: 192W typical (110V)
Dimensions (W x D x H): 303.5 x 234.5 x 112.4 mm
Weight: 3.3 kg

General (12)

Projection System: DLP
Light Source Life: 20,000 h
Zoom Ratio: 1.2x
Projection Offset: 102.5%
Rec. 709 Coverage: 95%
Keystone Adjustment: 2D, vertical ±30 degrees, horizontal ±30 degrees
Projection Technology: Single-chip DLP
Light Source: Laser, 20,000 hours
Throw Ratio: 0.69 - 0.83:1
Zoom: 1.2x
Keystone Correction: 2D: vertical +/-30 degrees, horizontal +/-30 degrees
Noise Level: 32 dB normal / 29 dB eco

Call 020 3815 8642

Throw distance guide

With its 0.69 to 0.83:1 throw ratio, here's how far the projector needs to sit from the screen for common 16:9 image sizes. Try our throw distance calculator for your exact room.

Try a size

100"

16:9 diagonal image


2.21 m × 1.25 m

Lens position

1.5 m to 1.8 m

Side view: drag the projector to try its available lens positions

Position fits

Image size	Image dimensions	Lens distance range
60"	1.33 m × 0.75 m	0.9 m to 1.1 m
80"	1.77 m × 1.00 m	1.2 m to 1.5 m
100"	2.21 m × 1.25 m	1.5 m to 1.8 m
120"	2.66 m × 1.49 m	1.8 m to 2.2 m
150"	3.32 m × 1.87 m	2.3 m to 2.8 m

Planning from a real wall? Use the projector screen size calculator to upload a photo, preview the image to scale and find projectors that fit within your maximum available space. Replacing an existing projector? The projector replacement calculator checks whether this lens covers the ratio your current mount needs.

Distances are lens-to-screen, calculated from the manufacturer's stated throw ratio; allow for lens shift and mounting hardware. Always confirm against the manufacturer's installation guide before fixing mounts.
