Home / Extenders / ATEN VS1814T 4-Port HDMI HDBaseT Splitter
ATEN

ATEN VS1814T 4-Port HDMI HDBaseT Splitter

£1,533.32inc. VAT
£1,277.77 ex. VAT
Out of stock
1
  • Visa
  • Mastercard
  • American Express
  • PayPal

Or 3 interest-free payments of £511.11 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • Sourced through UK distribution
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Call 01342 580255
Return within 14 days
Installation services availablePurchase orders: education customers only
2 Years Warranty Included
Key specifications
Video Input — Interfaces1 x HDMI Type A Female (Black)
Video Input — Impedance100 Ω
Video Input — Max. Distance1.8 m
Video Output — Interfaces1 x HDMI Type A Female (Black) - Local Output; 4 x RJ-45 Female
Video Output — Impedance100 Ω
Video — Max. Data Rate10.2 Gbps (3.4 Gbps Per Lane)
Video — Max. Pixel Clock340 MHz
Video — ComplianceHDMI (3D, Deep Color, 4K); HDCP Compatible; Consumer Electronics Control (CEC); HDBaseT Compatible
All 15 specifications

Description

The ATEN VS1814T takes one HDMI source and drives 4 displays over structured cabling, so a single player or PC can feed screens spread across a building without a separate extender behind each one.

Also in this range:VS1818T Full specifications Datasheet Compare alternatives

Video is carried at up to 100 m (Depends on connected receiver). Control passes down the same cable, so IR and RS-232 from the head end still reach the display.

Housing is metal. Supplied to order from TopAV with ATEN's 36-month warranty.

Call 01342 580255

Key features

Rack-mountable

The VS1814T is compatible with the VE812R HDMIover Single Cat 5 Receiver.

Interfaces

1 x HDMI Type A Female (Black).

Impedance

100 Ω.

Technical specifications

Display
Video — Max. ResolutionUp to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4); (Depends on connected receiver)
Connectivity
Video Input — Interfaces1 x HDMI Type A Female (Black)
Video Input — Impedance100 Ω
Video Input — Max. Distance1.8 m
Video Output — Interfaces1 x HDMI Type A Female (Black) - Local Output; 4 x RJ-45 Female
Video Output — Impedance100 Ω
Audio — Input1 x HDMI Type A Female (Black)
Audio — Output1 x HDMI Type A Female (Black)
Connectors — Power1 x 3-Prong AC Socket (Black)
Certifications & Warranty
Video — ComplianceHDMI (3D, Deep Color, 4K); HDCP Compatible; Consumer Electronics Control (CEC); HDBaseT Compatible
General
Video — Max. Data Rate10.2 Gbps (3.4 Gbps Per Lane)
Video — Max. Pixel Clock340 MHz
Video — Max. DistanceUp to 100 m (Depends on connected receiver)
Control — RS-232Connector: 1 x DB-9 Female (Black); Serial Control Pin Configurations: Pin2 = Tx, Pin 3=Rx, Pin 5= Gnd; Baud Rate and Protocol:; Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No
EDID SettingsEDID Mode: Default / Port 1 / Auto / Learn
Call 01342 580255

Documents

ATEN VS1814T manufacturer datasheet (PDF)
