Home / Switches / ATEN KH1508Ai 1-Local/Remote Shared Access 8-Port Multi-Interface Cat 5 KVM over IP Switch

ATEN

ATEN KH1508Ai 1-Local/Remote Shared Access 8-Port Multi-Interface Cat 5 KVM over IP Switch

Name: ATEN KH1508Ai 1-Local/Remote Shared Access 8-Port Multi-Interface Cat 5 KVM over IP Switch
Brand: ATEN
SKU: KH1508AI
Price: 890.29 GBP
Availability: OutOfStock

£890.29inc. VAT

£741.91 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

Or 3 interest-free payments of £296.77 with PayPal Pay in 3.

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Computer Connections - Direct8

Computer Connections - Maximum128 (via Daisy-chain)

Port SelectionOSD; Hotkey; Pushbutton

KVM Ports8 x RJ-45 Female

Console Ports2 x USB Type-A Female (White); 1 x 6-pin Mini-DIN Female (Purple) ; 1 x 6-pin Mini-DIN Female (Green); 1 x HDB-15 Female (Blue)

LAN Ports1 x RJ-45 Female

Daisy Chain Ports1 x DB-25 Male

Keyboard / MousePS/2; USB

All 15 specifications

Description

The ATEN KH1508Ai is a rack-mounted KVM switch that puts 8 servers behind a single keyboard, monitor and mouse. Its over-IP console adds browser-based access, so the same estate can be reached from a desk elsewhere on the network or across a VPN without another console being wired in. Cascading takes the addressable total to 128 (via daisy-chain).

Also in this range:KH1516Ai Full specifications Datasheet Compare alternatives

Server connections are 8 x RJ-45 Female. The local console attaches through 2 x USB Type-A Female (White), 1 x 6-pin Mini-DIN Female (Purple), 1 x 6-pin Mini-DIN Female (Green), 1 x HDB-15 Female (Blue). Ports can be selected by OSD; Hotkey; Pushbutton. Video is supported to 1600 x 1200 @ 60Hz (non-FHD version) 1920 x 1200 @ 60Hz (FHD version). Keyboard and mouse emulation covers PS/2; USB, so attached machines boot cleanly whether or not the switch is focused on them.

Deployed in an AV rack the switch removes the need for a monitor per source, and pairs naturally with ATEN's LCD console drawers and eco PDUs to build a single serviceable equipment stack. Operating temperature is 0 - 40°C. Unit weight is 2.68 kg ( 5.9 lb ). ATEN provides a three-year warranty. This item is available to order from TopAV.

Key features

8 servers, one console

Direct connection for 8 computers, expandable to 128 (via Daisy-chain).

Cat 5 cabling

Server ports are 8 x RJ-45 Female, so each machine needs one thin structured cable rather than a three-cable KVM bundle.

Remote access over IP

A browser-based console reaches the attached machines from elsewhere on the network without a second console being wired in.

Video support

Video from attached computers is carried at 1600 x 1200 @ 60Hz (non-FHD version); 1920 x 1200 @ 60Hz (FHD version).

Technical specifications

Connectivity

Computer Connections - Direct8

Computer Connections - Maximum128 (via Daisy-chain)

Port SelectionOSD; Hotkey; Pushbutton

KVM Ports8 x RJ-45 Female

Console Ports2 x USB Type-A Female (White); 1 x 6-pin Mini-DIN Female (Purple) ; 1 x 6-pin Mini-DIN Female (Green); 1 x HDB-15 Female (Blue)

LAN Ports1 x RJ-45 Female

Daisy Chain Ports1 x DB-25 Male

Maximum Input Power Rating100–240 VAC; 50/60 Hz; 1A

Power & Physical

Power ConsumptionAC110V:8.7W:49BTU/h; AC220V:8.7W:49BTU/h

Weight2.68 kg ( 5.9 lb )

General

Keyboard / MousePS/2; USB

Operating Temperature0 - 40°C

Storage Temperature-20 - 60°C

Humidity0–80% RH; Non-condensing

HousingMetal

Documents

ATEN datasheet (PDF) covering the KH1508AI: kh1508ai-1516ai-1-Local-Remote-Shared-Access-8-16-Port-Multi-Interface-Cat-5-KVM-over-IP-Switch-datasheet-en.pdf
