ATEN KE9950ATC 4K DisplayPort KVM over IP Air Traffic Control Bundle (2 x Transmitter, 1 x Receiver)

Name: ATEN KE9950ATC 4K DisplayPort KVM over IP Air Traffic Control Bundle (2 x Transmitter, 1 x Receiver)
Brand: ATEN
SKU: KE9950ATC
Price: 5589.30 GBP
Availability: OutOfStock

£5,589.30inc. VAT

£4,657.75 ex. VAT

Out of stock

Visa
Mastercard
American Express
PayPal

4.5 on Trustpilot · 14 reviews

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →

Sourced through UK distribution
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Call 01342 580255

Return within 14 days

Installation services available Purchase orders: education customers only

2 Years Warranty Included

Key specifications

Video ResolutionUp to 3840 x 2160 @ 30Hz

Latency< 5ms

Console Ports2 x USB Type A Female (White); 1 x DisplayPort Female (Black); 1 x Mini Stereo Jack (Green); 1 x Mini Stereo Jack (Pink); 1 x DB-9 Male (Black)

KVM PortsTransmitter: 1 x USB Type B Female (White); 1 x DisplayPort Female (Black); 1 x Mini Stereo Jack (Green); 1 x Mini Stereo Jack (Pink); 1 x DB-9 Female (Black)

LAN Ports1 x RJ-45 (Black); 1 x SFP Slot

Connectors - Power2 x DC Jack (Black)

Keyboard / MouseUSB

Power ConsumptionDC5V:9.51W:49BTU/h; DC5V:8.03W:63BTU/h

All 15 specifications

Description

The ATEN KE9950ATC is a pre-configured KVM over IP bundle assembled by ATEN for air traffic control and similar always-on operator positions. It ships as two KE9950T DisplayPort transmitters and one KE9950R DisplayPort receiver, so a single operator console can be switched between two separate host machines without a second desk position or a second set of peripherals.

Also in this range:KE6920ATC Full specifications Datasheet Compare alternatives

Video is carried at up to 3840 x 2160 with quoted switching latency under 5 ms, over standard Gigabit Ethernet or fibre using the SFP slot on each unit. Keyboard, mouse, audio and RS-232 travel with the video, so a serial-controlled device attached to a host stays reachable from the operator side. The bundle includes the DisplayPort and USB KVM cables, power adapters, cords and mounting kits needed to commission all three units.

Because the endpoints are standard KE9950 units, the bundle can later be absorbed into a larger KVM over IP matrix managed by ATEN's CCKM control centre rather than being replaced. SFP modules (2A-136G / 2A-137G) are ordered separately where a fibre run is required. ATEN provides a three-year warranty. This item is available to order from TopAV.

Call 01342 580255

Key features

Two hosts, one console

Ships as two KE9950T transmitters and one KE9950R receiver, so an operator position can be switched between two separate machines.

4K over standard networking

Carries up to 3840 x 2160 video with sub-5 ms switching latency over Gigabit Ethernet, or over fibre using the SFP slot in each unit.

Peripherals travel with the picture

USB keyboard and mouse, analogue audio and RS-232 are extended alongside the video, so serial-controlled hardware stays reachable.

Complete kit

DisplayPort and USB KVM cables, power adapters, cords, mounting kits and instructions are supplied for all three units.

Technical specifications

Display

Video ResolutionUp to 3840 x 2160 @ 30Hz

Connectivity

Console Ports2 x USB Type A Female (White); 1 x DisplayPort Female (Black); 1 x Mini Stereo Jack (Green); 1 x Mini Stereo Jack (Pink); 1 x DB-9 Male (Black)

KVM PortsTransmitter: 1 x USB Type B Female (White); 1 x DisplayPort Female (Black); 1 x Mini Stereo Jack (Green); 1 x Mini Stereo Jack (Pink); 1 x DB-9 Female (Black)

LAN Ports1 x RJ-45 (Black); 1 x SFP Slot

Connectors - Power2 x DC Jack (Black)

Power & Physical

Power ConsumptionDC5V:9.51W:49BTU/h; DC5V:8.03W:63BTU/h

Weight1.27 kg ( 2.8 lb )

Dimensions (L x W x H)22.75 x 17.16 x 5.48 cm ; (8.96 x 6.76 x 2.16 in.)

General

Latency< 5ms

Keyboard / MouseUSB

Operating Temperature0–50°C

Storage Temperature-20–60°C

Humidity0–95% RH, Non-condensing

HousingMetal

Switches - Reset1 x Semi-recessed Pushbutton

Call 01342 580255

Documents

ATEN datasheet (PDF) covering the KE9950ATC: KE9950ATC-KE9950-Air-Traffic-Control-Bundle-Solution-datasheet-en.pdf
