Home / Touch Screen Monitors / iiyama TF2234MC-B7AGB 22" PCAP Touch Screen Monitor
iiyama

iiyama TF2234MC-B7AGB 22" PCAP Touch Screen Monitor

£447.37inc. VAT
£372.81 ex. VAT
In stock, dispatched within 2 working days
1

Seen it cheaper? We price-match genuine like-for-like quotes. How it works

Bought in the UK, backed in the UKWhy it matters →
  • In UK stock, ships from the UK
  • UK manufacturer warranty
  • UK-based engineers
  • No import duty or customs charges
  • GBP pricing, UK VAT invoices
Return within 14 days
Manufacturer warranty
Installation services available
Key specifications
Size Band20 - 31"
Screen Size22 in
Panel Diagonal21.5" (54.6 cm)
Resolution1920 x 1080 (Full HD)
Brightness300 cd/m²
Panel Brightness350 cd/m² (before touch glass)
Contrast Ratio1000:1 (with touch glass)
Touch Points10 points
All 13 specifications
Talk to an Expert

Key features

22" Black, LED Touchscreen Monitor, Full HD, VGA, DisplayPort and HDMI

The ProLite TF2234MC-B7AGB uses PCAP Touch technology, and it is built into an eye-catching bezel with edge-to-edge glass. Featuring IPS LCD Screen technology, it offers exceptional colour performance and wide viewing angles. The higher brightness ensures crispy and clear images, even in a bright environment. In addition to the superb image quality, the screen is suitable for demanding environments. It comes with a rugged bezel and IP65 rating, meaning the monitor is dust and water resistant from the front. The Anti Glare Glass helps to avoid issues with reflections and external light sources affecting contrast and sharpness. The ProLite TF2234MC-B7AGB is the ideal screen for kiosk integrators and a superb display for use as Interactive Digital Signage, Instore Retail and Interactive Presentation display. For ease of integration, this monitor can be equipped with optional external mounting brackets (OMK1-1).

TOUCH TECHNOLOGY - CAPACITIVE

This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.

AG COATING

The anti-glare coating is used in professional-grade displays to help avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. It also makes the screen less susceptible to dust, grease and dirt marks.

OPEN FRAME BRACKETS

This open frame monitor can be equipped with optional external mounting brackets. It guarantees easy installation and makes it an ideal solution for kiosk integrators and In-store Retail.

IPS

IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.

TOUCH THROUGH-GLASS

This through glass touch screen works right through glass and can turn glass surfaces into an interactive touch screen display. Use it on storefront windows, real estate office, in-store for POS or restaurants.

Technical specifications

Size Band20 - 31"
Screen Size22 in
Panel Diagonal21.5" (54.6 cm)
Resolution1920 x 1080 (Full HD)
Brightness300 cd/m²
Panel Brightness350 cd/m² (before touch glass)
Contrast Ratio1000:1 (with touch glass)
Touch Points10 points
Touch TechnologyProjected capacitive (PCAP)
Operating SystemNone — external source required (Windows and Linux plug-and-play)
Aspect Ratio16:9
OrientationLandscape, portrait or face-up
Panel TypeIPS LED with anti-glare glass
