The Extron DTP3 R 201 is a long distance, digital twisted pair receiver that works with Extron DTP3‑enabled products to extend HDMI, audio, and bidirectional RS‑232 signals up to 330 feet (100 meters) over a shielded CAT 6A cable. It supports video resolutions up to 4K/60 at 4:4:4 color sampling and complies with HDCP 2.3. For maximum image quality and minimal latency, all supported video resolutions are transported without compression. The receiver features stereo audio de-embedding for convenient installation in professional environments. The compact enclosure size and flexible remote power capability make the DTP3 R 201 ideal for discreet placement behind displays, within equipment racks, or wherever needed to meet application requirements.

The DTP3 R 201 enables the reliable, long distance transmission of HDMI 2.0b signals, supporting data rates up to 18 Gbps, HDR, Deep Color up to 12‑bit, 3D, and embedded HD lossless audio formats. In addition, DDC communication of EDID and HDCP is continuously maintained between a source and display, ensuring direct compatibility and optimal signal transmission between devices.

Convenient Control and Power

For added convenience, a USB-C configuration port on the front panel offers ready access to information and easy updating of firmware. Configuration of the DTP3 R 201 is made simple with Extron’s PCS - Product Configuration Software and its user-friendly GUI that is very easy to navigate. This software application allows for expedited setup, commissioning, real-time operation and monitoring.

The DTP3 R 201 can be remotely powered over the same shielded twisted pair cable by a DTP3-enabled product. In addition, it can be configured to provide power to a connected transmitter, allowing both devices to share one power supply.

To support displays and other output devices at remote locations, the receiver can be integrated with other DTP3-enabled products. It is housed in a 1" (2.5 cm) high, quarter rack width metal enclosure. The low-profile design allows for discreet placement in lecterns and behind flat-panel displays.

To ensure optimal performance with DTP3 systems, Extron recommends XTP DTP 22 cables and accessories. These 22-gauge shielded twisted pair cables, shielded RJ‑45 plugs, jacks, and couplers have been engineered for optimum performance for DTP3 products running at 18 Gbps. Extron XTP DTP 22 cable bandwidth is verified to 500 MHz and utilizes a S/FTP design with four shielded 22 AWG twisted pair conductors inside an overall braided shield for superior performance and noise immunity.

Features

Receives HDMI plus control up to 330' (100 m) over a shielded CAT 6A cable — The DTP3 R 201 provides high reliability and maximum performance on an economical and easily installed cable infrastructure.
Supports computer and video resolutions up to 4K/60 @ 4:4:4, including 5K — Support of 4K/60 at 4:4:4 color sampling requires connection to matching DTP3 products.
Supports ultra-wide aspect ratios, including 21:9 and 5K
Stereo audio de‑embedding
HDCP 2.3 compliant — Ensures display of content-protected 4K video media and maintains interoperability with earlier versions of HDCP.
Supported HDMI 2.0b specification features include data rates up to 18 Gbps, HDR, Deep Color up to 12‑bit, 3D, HD lossless audio formats, and CEC
Compatible with DTP3 and DTP‑enabled products — Enables mixing and matching with desktop and wallplate transmitters, as well as other DTP-enabled products to meet application requirements. Not compatible with DTP2 products.
Remote power capability with DTP3 products — For simplified installation, the receiver can be remotely powered by a DTP3‑enabled product over the twisted pair connection. It can also be configured to provide power to the connected DTP3 transmitter.
Extron XTP DTP 22 shielded twisted pair cable is strongly recommended for optimal performance
Compatible with CAT 6A shielded twisted pair cable
Bidirectional RS‑232 pass-through for AV device control — Bidirectional RS‑232 control signals can be transmitted alongside the video signal, allowing remote AV devices to be controlled without the need for additional cabling.
Support for HDR – High Dynamic Range Video — Enables greater contrast range and wider color gamut by providing the necessary video bandwidth, color depth, and metadata interchange capability for HDR video.
Supports multiple embedded audio formats — The DTP3 R 201 is compatible with a broad range of multi-channel audio signals, providing reliable operation with HDMI sources.
Supports EDID and HDCP transmission — DDC channels are actively buffered, allowing continuous communication between source and display.
CEC insertion — A control processor can insert CEC commands at select DTP3 switchers to control devices connected at the receiver's HDMI output.
Front panel USB‑C^® configuration port — Provides convenient access for information and firmware updates.
LED indicators for signal presence, power, and link status — Provide visual indication of system status for real-time feedback and monitoring of key performance parameters.
RJ-45 signal and link LED indicators for DTP3 port — Provide a means for validating signal flow and operation, allowing quick identification of connectivity issues.
Easy setup and commissioning with Extron's PCS - Product Configuration Software — Conveniently configure multiple products using a single software application.
1" (2.5 cm) high, quarter rack width metal enclosure — With a low profile enclosure, the device can be installed discreetly wherever needed.
DoDIN APL Approved Product available — This product is available as a Department of Defense Information Network Approved Product version upon request. Please contact Extron with your specific needs.
Includes LockIt^® cable lacing brackets — Securely fastens HDMI or USB C^® cables to a device, eliminating risk of disconnection.
Optional, external Extron Everlast™ power supply available, part # 70‑1174‑01 — Provides worldwide power compatibility with high demonstrated reliability and low power consumption.
